Bussmann Series RM60600-1CR
Edison RM60600-1CR RM600 Modular Knife Blade Fuse Block, 600 VAC, 600 A, R Class, 4 AWG to 500 kcmil Wire, 1 Pole
Bussmann Series RM60600-1CR
Edison RM60600-1CR RM600 Modular Knife Blade Fuse Block, 600 VAC, 600 A, R Class, 4 AWG to 500 kcmil Wire, 1 PoleNon-stock product. Available to order - lead time may vary.
BrandBussmann Series
MFG #RM60600-1CR
Werner Part #3997528
UPC051712391061
Non-stock product. Available to order - lead time may vary.
BrandBussmann Series
MFG #RM60600-1CR
Werner Part #3997528
UPC051712391061
Product Description
Edison Fuse Block, Modular Knife Blade, Series: RM600, 600 VAC, 600 A, 1 Poles, Class: R, Fuse Holder Code: U, Box Lug, 4 AWG to 500 kcmil Wire, Panel Mount, 13.38 in Fuse Length, 3.13/2.88 in Fuse Dia, -40 to 120 deg C, For Use With: Low-Peak LPS-RK-SP and LPS-RK-SPI, Fusetron FRS-R, Limitron KTS-R, KWS-R and PVS-R Fuse, Thermoplastic, 15.1 in L x 4.9 in W x 6 in H
Attributes
Documents
Applications
Features
Attributes
ClassR
Connection TypeBox Lug
Country of OriginMX
Dimensions15.1 in L x 4.9 in W x 6 in H
Fuse Diameter3.13/2.88 in
Fuse Holder CodeU
Fuse Length13.38 in
ManufacturerEaton
MaterialThermoplastic
Mounting TypePanel
Number of Poles1
SeriesRM600
Size of Wire4 AWG to 500 kcmil
Suitable For Use WithLow-Peak LPS-RK-SP and LPS-RK-SPI, Fusetron FRS-R, Limitron KTS-R, KWS-R and PVS-R Fuse
Temperature Rating-40 to 120 deg C
Type / StyleModular Knife Blade
Voltage Rating600 V AC
Applications
Electrical Assemblies, Panels, EOEMs, Critical Power, Factory Automation, Renewable Energy, HVAC, Building/Elevator Controls, Building Entrance and Process Industries Applications
Features
- Integral dovetails allow snapping together multiple poles at point of use for greater application flexibility
- Up to four mounting holes per pole increase installation flexibility
- Standard phase barriers between poles for additional safety
- Design meets UL creep and clearance requirements for industrial control circuits (UL 508 and UL 845)
- 200 to 600 A blocks meet the higher UL creep and clearance requirements for industrial power distribution standards (UL 98, UL 69, UL 489, UL 891 and UL 869A)
- Standard fuse clip reinforcing springs enhance electrical contact
- Blocks dovetail together to assemble required number of poles
- 3.13 in dia for Fusetron and Limitron, 2.88 in dia for Low-Peak fuses
