Panduit LCDX500-12-6

Panduit Pan-Lug LCDX500-12-6 2-Hole Compression Connector Lug, 500 kcmil, 535.3 kcmil Copper Conductor, Die Code: P99, 42.767 in Stud, Tin Plated Copper
Panduit Pan-Lug LCDX500-12-6 2-Hole Compression Connector Lug, 500 kcmil, 535.3 kcmil Copper Conductor, Die Code: P99, 42.767 in Stud, Tin Plated Copper

Panduit LCDX500-12-6

Panduit Pan-Lug LCDX500-12-6 2-Hole Compression Connector Lug, 500 kcmil, 535.3 kcmil Copper Conductor, Die Code: P99, 42.767 in Stud, Tin Plated Copper
Non-stock product. Available to order - lead time may vary.

BrandPanduit

MFG #LCDX500-12-6

Werner Part #3865079

UPC074983436477

Non-stock product. Available to order - lead time may vary.

BrandPanduit

MFG #LCDX500-12-6

Werner Part #3865079

UPC074983436477

Product Description

Panduit Pan-Lug Compression Connector Lug, 2-Hole, Series: LCDX, Copper Conductor, 500 kcmil, 535.3 kcmil Conductor, Die Code: P99, 35 kV, 42.767 in Stud, Straight Tongue, 1.89 in W x 0.26 in THK Tongue, 5.26 in Overall Length, Standard Barrel, 1.03 in ID x 1.3 in OD x 1.48 in L Barrel, 1.56 in L Wire Strip, 1-3/4 in Stud Hole Spacing, 90 deg C, 1.56 in Mounting Hole, Tin Plated Copper, Pink
Attributes
Barrel Size1.03 in ID x 1.3 in OD x 1.48 in L
Barrel TypeStandard
ColorPink
Conductor size500 kcmil, 535.3 kcmil
Conductor TypeCopper
Country of OriginMX
Die CodeP99
ManufacturerPanduit
MaterialTin Plated Copper
Mounting Hole Type1.56 in
Overall Length5.26 in
SeriesLCDX
Stud Size42.767 in
Temperature Rating90 deg C
Tongue Size1.89 in W x 0.26 in THK
Tongue TypeStraight
Type2-Hole
Type / Style2-Hole
Voltage Rating35 kV
