Panduit LCD3/0-38D-X
Panduit Pan-Lug LCD3/0-38D-X 2-Hole Compression Connector Lug, 3/0 AWG Stranded Copper Conductor, Die Code: P50, 42.95 in Stud, Tin Plated Copper
Panduit LCD3/0-38D-X
Panduit Pan-Lug LCD3/0-38D-X 2-Hole Compression Connector Lug, 3/0 AWG Stranded Copper Conductor, Die Code: P50, 42.95 in Stud, Tin Plated CopperNon-stock product. Available to order - lead time may vary.
BrandPanduit
MFG #LCD3/0-38D-X
Werner Part #1097544
UPC074983383290
Non-stock product. Available to order - lead time may vary.
BrandPanduit
MFG #LCD3/0-38D-X
Werner Part #1097544
UPC074983383290
Product Description
Panduit Pan-Lug Compression Connector Lug, 2-Hole, Series: LCD, Stranded Copper Conductor, 3/0 AWG Conductor, Die Code: P50, 35 kV, 42.95 in Stud, Straight Tongue, 0.96 in W x 0.13 in THK Tongue, 3.33 in Overall Length, Standard Barrel, 0.51 in ID x 0.64 in OD x 1.14 in L Barrel, 1 in Stud Hole Spacing, 1-3/16 in L Wire Strip, 90 deg C, 1.19 in Mounting Hole, Tin Plated Copper, Orange
Attributes
Documents
Features
Specifications
Attributes
Barrel Size0.51 in ID x 0.64 in OD x 1.14 in L
Barrel TypeStandard
ColorOrange
Conductor size3/0 AWG
Conductor TypeStranded Copper
Country of OriginMX
Die CodeP50
ManufacturerPanduit
MaterialTin Plated Copper
Mounting Hole Type1.19 in
Overall Length3.33 in
SeriesLCD
Stud Size42.95 in
Temperature Rating90 deg C
Tongue Size0.96 in W x 0.13 in THK
Tongue TypeStraight
Type2-Hole
Type / Style2-Hole
Voltage Rating35 kV
Documents
Features
- Color-coded barrels marked with Panduit and specified competitor die index numbers for proper crimp die selection
- Inspection window to visually assure full conductor insertion
- Tin plated to inhibit corrosion
- For use with stranded copper conductors
- Consult cable manufacturer for voltage stress relief instructions with applications greater than 2000 V
Specifications
1 in Stud Hole Spacing, 1-3/16 in L Wire Strip
