Panduit LCC1/0-12W-X
Panduit® Pan-Lug™ LCC1/0-12W-X LCC-W 2-Hole Compression Lug, 1/0 AWG Copper Conductor, Die Code: P42, 1/2 in Stud, Tin Plated Copper
Panduit LCC1/0-12W-X
Panduit® Pan-Lug™ LCC1/0-12W-X LCC-W 2-Hole Compression Lug, 1/0 AWG Copper Conductor, Die Code: P42, 1/2 in Stud, Tin Plated CopperOut of Stockmore info
|
BrandPanduit
MFG #LCC1/0-12W-X
Werner Part #3978269
UPC074983798063
Out of Stockmore info
|
BrandPanduit
MFG #LCC1/0-12W-X
Werner Part #3978269
UPC074983798063
Product Description
Panduit® Pan-Lug™ Compression Lug, 2-Hole, Series: LCC-W, Copper Conductor, 1/0 AWG Conductor, Die Code: P42, 35 kV, 1/2 in Stud, Straight Tongue, 0.8 in W x 0.12 in THK Tongue, 4.74 in Overall Length, Long With Inspection Window Barrel, 0.39 in ID x 0.52 in OD x 1.44 in L Barrel, 1-1/2 in L Wire Strip, 1-3/4 in Stud Hole Spacing, 90 deg C, 1-1/2 in Mounting Hole, Tin Plated Copper, Pink
Attributes
Documents
Features
Specifications
Attributes
Barrel Size0.39 in ID x 0.52 in OD x 1.44 in L
Barrel TypeLong
ColorPink
Conductor size36526 AWG
Conductor TypeStranded Copper
Country of OriginMexico
Die CodeP42
ManufacturerPanduit
MaterialTin Plated Copper
Mounting Hole Type1-1/2 in
Overall Length4.74 in
SeriesLCC-W
Temperature Rating90 deg C
Tongue Size0.8 in W x 0.12 in THK
Tongue TypeStraight
Type2-Hole
Type / Style2-Hole
Voltage Rating35 kV
Documents
Features
Long barrel maximizes number of crimps and provides premium wire pull-out strength and electrical performanceInspection window to visually assure full conductor insertionColor-coded barrels marked with Panduit and specified competitor die index numbers for proper crimp die selectionTin-plated to inhibit corrosionFor use with stranded copper conductors
Specifications
1-1/2 in L Wire Strip, 1-3/4 in Stud Hole Spacing
