Panduit LAM4D250-12-1Y
Panduit® LAM4D250-12-1Y 4-Barrel Mechanical Lug, 6 AWG to 250 kcmil Stranded Aluminum/Copper Conductor, 1/2 in Stud, 4 Bolt Holes, Aluminum
Panduit LAM4D250-12-1Y
Panduit® LAM4D250-12-1Y 4-Barrel Mechanical Lug, 6 AWG to 250 kcmil Stranded Aluminum/Copper Conductor, 1/2 in Stud, 4 Bolt Holes, AluminumNon-stock product. Available to order - lead time may vary.
Non-stock product. Available to order - lead time may vary.
Product Description
Panduit® Mechanical Lug, 4-Barrel, Series: LAM4D, Stranded Aluminum/Copper Conductor, 6 AWG to 250 kcmil Conductor, 1/2 in Stud, 4 Bolt Holes, 3.25 in L x 4.04 in W x 0.31 in THK Tongue, Straight Tongue, 600 VAC, Specifications: 5/16 in Hex, 1-3/4 in Stud Hole Spacing, 1 in L Wire Strip, 90 deg C, Aluminum, Tin Plated, 4.25 in L x 4 in W x 1.19 in H Dimensions
Attributes
Documents
Features
Specifications
Attributes
Conductor size6 AWG to 250 kcmil
Conductor TypeAluminum/Copper/Stranded
Country of OriginUnited States
Dimensions4.25 in L x 4 in W x 1.19 in H
FinishTin Plated
ManufacturerPanduit
MaterialAluminum
Number of Bolt Holes4
SeriesLAM4D
Temperature Rating194 deg F
Tongue Size3.25 in L x 4.04 in W x 0.31 in THK
Tongue TypeStraight
Type4-Barrel
Type / Style4-Barrel
Voltage Rating600 VAC
Documents
Features
Made from high strength, extruded aluminum alloy to provide premium electrical and mechanical performanceWide wire range taking capability minimizes inventory requirementsInspection window to visually assure full conductor insertionPlated steel or aluminum set screw provides high strength, durable electrical contact between conductor and connectorFour barrel provides termination of four conductorsTin plated to inhibit corrosion
Specifications
5/16 in Hex, 1 in L Wire Strip, 1-3/4 in Stud Hole Spacing, 4 Conductors
