Panduit LAA1/0-38-X

Panduit Pan-Lug LAA1/0-38-X 1-Hole Dual Rated Compression Lug, 1/0 AWG Stranded Aluminum/Copper Conductor, Die Code: P50, 3/8 in Stud, Aluminum
Panduit Pan-Lug LAA1/0-38-X 1-Hole Dual Rated Compression Lug, 1/0 AWG Stranded Aluminum/Copper Conductor, Die Code: P50, 3/8 in Stud, Aluminum

Panduit LAA1/0-38-X

Panduit Pan-Lug LAA1/0-38-X 1-Hole Dual Rated Compression Lug, 1/0 AWG Stranded Aluminum/Copper Conductor, Die Code: P50, 3/8 in Stud, Aluminum
In Stock: 34more info

BrandPanduit

MFG #LAA1/0-38-X

Werner Part #1103970

UPC074983910267

In Stock: 34more info

BrandPanduit

MFG #LAA1/0-38-X

Werner Part #1103970

UPC074983910267

Product Description

Panduit Pan-Lug Compression Lug, 1-Hole Dual Rated, Series: LLA, Stranded Aluminum/Copper Conductor, 1/0 AWG Conductor, Die Code: P50, 35 kV, 3/8 in Stud, Straight Tongue, 1.25 in L x 0.88 in W x 0.25 in THK Tongue, 3.22 in Overall Length, Long/Standard Barrel, 0.39 in ID x 0.64 in OD x 1.3 in L Barrel, Specifications: 1-9/16 in L Wire Strip, Tin Plated Finish, 90 deg C, 1.56 in Mounting Hole, Aluminum, Tan
Attributes
Barrel Size0.39 in ID x 0.64 in OD x 1.3 in L
Barrel TypeLong/Standard
ColorTan
Conductor size1/0 AWG
Conductor TypeStranded Aluminum/Copper
Country of OriginIN
Die CodeP50
ManufacturerPanduit
MaterialAluminum
Mounting Hole Type1.56 in
Overall Length3.22 in
SeriesLLA
Stud Size3/8 in
Temperature Rating90 deg C
Tongue Size1.25 in L x 0.88 in W x 0.25 in THK
Tongue TypeStraight
Type1-Hole Dual Rated
Type / Style1-Hole
Voltage Rating35 kV
