Leviton BR15-T
Leviton BR15-T Heavy Duty Narrow Body Straight Blade Duplex Receptacle, 125 V AC, 15 A, 2 Poles, 3 Wires, Light Almond
Leviton BR15-T
Leviton BR15-T Heavy Duty Narrow Body Straight Blade Duplex Receptacle, 125 V AC, 15 A, 2 Poles, 3 Wires, Light AlmondIn Stock: 40more info
|
BrandLeviton
MFG #BR15-T
Werner Part #2256731
UPC078477273005
In Stock: 40more info
|
BrandLeviton
MFG #BR15-T
Werner Part #2256731
UPC078477273005
Product Description
Leviton Straight Blade Duplex Receptacle, Heavy Duty Narrow Body, 125 V AC, 15 A, 1/2 hp, 2 Pole, 3 Wires, NEMA 5-15R NEMA Rating, Commercial Grade, NEMA WD-1/WD-6 Enclosure, -40 to 60 deg C, Back/Side Wire Terminal, Nylon, Light Almond, 4.06 in H x 1.56 in W x 1.09 in D Dimensions
Attributes
Documents
Warranty
Features
Specifications
Attributes
ColorLight Almond
Country of OriginUS
Dimensions4.06 in H x 1.56 in W x 1.09 in D
Enclosure TypeNEMA WD-1/WD-6
GradeCommercial
Horsepower1/2 hp
ManufacturerLeviton
MaterialNylon
NEMA RatingNEMA 5-15R
Number of Poles2
Number of Wires3
Temperature Rating-40 to 60 deg C
Terminal TypeBack/Side Wire
TypeHeavy Duty Narrow Body
Type / StyleHeavy Duty Narrow Body
Voltage Rating125 V AC
Documents
Warranty
10 Years
Features
- Manufactured to withstand the demands of commercial and institutional applications
- Heavy duty brass power contacts for maximum conductivity and plug retention
- Shallow design for maximum wiring room in box
Specifications
Standards/Approvals: ARRA Compliant|Buy American Act Compliant|RoHS Compliant|ANSI (C-73)|CSA C22.2 No. 42 File No. 152105|UL 498 File NO E13399 Listed|NOM Certified|UL94 Flammability Rating
