Cutler-Hammer Series XRU2D24U
EATON Cutler-Hammer Series XRU2D24U Fixed Standard Terminal Block Relay
Cutler-Hammer Series XRU2D24U
EATON Cutler-Hammer Series XRU2D24U Fixed Standard Terminal Block RelayNon-stock product. Available to order - lead time may vary.
Non-stock product. Available to order - lead time may vary.
Product Description
EATON Cutler-Hammer Series EATON Terminal Block Relay, Fixed Standard, Series: XR Series, 6 A, 50 mW, 24 VDC Coil, DPDT, 2 Pole, DIN Rail Mount, Screw Terminal, IP67, -4 to 140 deg F, 0.55 in L x 3.15 in W x 3.7 in H
Attributes
Applications
Features
Specifications
Warranty
Attributes
Coil Voltage24 VDC
Contact FormDPDT
Country of OriginGermany
Dimensions0.55 in L x 3.15 in W x 3.7 in H
Enclosure TypeIP67
ManufacturerEaton
Mounting TypeDIN Rail
Number of Poles2
Power Rating50 mW
SeriesXR Series
Temperature Rating-4 to 140 deg F
Terminal TypeScrew
Applications
Automation Systems, Electromechanical Relays Guarantee a Safe Connection Between Process I/O and Electronic Controls
Features
- Pluggable relay allows for field replacement
- Functional plug-in bridges
- LED status indication
- Only 6.2 mm wide for 1-pole versions, 14 mm wide for 2-pole
- All common input voltages between 12 VDC to 120 VAC
- Equipped with a robust, miniature relay
- Environmentally friendly, cadmium-free contact material
- Easy, cost effective installation and replacement using the engagement lever
Specifications
- CSA Certified
- UL Listed
- cULus Listed
- CE Marked
Warranty
1 year
