Cutler-Hammer Series R4H3030FJ
EATON R4H3030FJ H -Frame Fusible Rotary Disconnect Switch, 600 V AC, 30 A, 20 hp, 22 hp, 3 Poles
Cutler-Hammer Series R4H3030FJ
EATON R4H3030FJ H -Frame Fusible Rotary Disconnect Switch, 600 V AC, 30 A, 20 hp, 22 hp, 3 PolesNon-stock product. Available to order - lead time may vary.
BrandCutler-Hammer Series
MFG #R4H3030FJ
Werner Part #3884256
UPC786685408750
Non-stock product. Available to order - lead time may vary.
BrandCutler-Hammer Series
MFG #R4H3030FJ
Werner Part #3884256
UPC786685408750
Product Description
EATON Rotary Disconnect Switch, H -Frame Fusible, Series: R4 Series, 600 V AC, 30 A, 20 hp, 22 hp, 3 ph, 3 Pole, 100/200 kA Short Circuit, Rotary Handle Actuator, Class J Insulation, DIN Rail Mount, Lug Terminal, 4.14 in L x 3.91 x 4.57 in H
Attributes
Documents
Applications
Warranty
Features
Attributes
Actuator TypePivot/Toggle Handle
Country of OriginFR
Dimensions4.14 in L x 3.91 x 4.57 in H
Enclosure TypeNEMA 1/3R/4/4X/12
FrameSE150
Frequency Rating50/60 Hz
Horsepower20 hp, 22 hp
Insulation TypeClass J
Interrupt Rating18 kA
ManufacturerEaton
Mounting TypePanel
Number of Poles3
Phase3
SeriesR4 Series
Short Circuit Current Rating100/200 kA
Size of Wire12 to 3/0 AWG
Temperature Rating104 deg F
Terminal TypeLug
Trip TypeElectronic LSI/Interchangeable
TypeH -Frame Fusible
Type / StyleFusible H Frame
Voltage600 VAC
Applications
Industrial Facilities, Factories, Control and Power Distribution Applications
Warranty
1 year
Features
- Load break functionality
- Double break contacts
- Compact footprints
- This function provides a simple alternative to a separately wired pushbutton
- Defeatable pistol handles automatically re-latch when the panel door is closed
- Front or side operation
- Flange operation
