Cutler-Hammer Series NS1-100-NA
EATON NS1-100-NA NZM Molded Case Circuit Breaker, 600 V AC, 100 A, 50 kA Interrupt, 3 Poles
Cutler-Hammer Series NS1-100-NA
EATON NS1-100-NA NZM Molded Case Circuit Breaker, 600 V AC, 100 A, 50 kA Interrupt, 3 PolesNon-stock product. Available to order - lead time may vary.
BrandCutler-Hammer Series
MFG #NS1-100-NA
Werner Part #4052234
Non-stock product. Available to order - lead time may vary.
BrandCutler-Hammer Series
MFG #NS1-100-NA
Werner Part #4052234
Product Description
EATON Molded Case Circuit Breaker, Series: NZM, 600 V AC, 100 A, 50/60 Hz Frequency, 50 kA Interrupt, 3 Pole, 1 ph, Rocker Lever Actuator, Screw Connection, IP40 Enclosure, -25 to 50 deg C, 3.465 in L x 3.543 in W x 5.709 in H Dimensions
Attributes
Documents
Applications
Features
Attributes
Actuator TypeRotary Handle
Connection TypeScrew
Country of OriginRO
Dimensions3.465 in L x 3.543 in W x 5.709 in H
Enclosure TypeIP40
FrameS0
Frequency Rating50/60 Hz
Interrupt Rating50 kA
ManufacturerEaton
Mounting TypeDIN Rail
Number of Poles3
Phase1
SeriesNZM
Temperature Rating-25 to 50 deg C
Trip TypeThermal/Magnetic
Voltage600 VAC
Documents
Applications
For circuit protection, panelbuilders and machinery OEMs
Features
- Compact structure, with four frame sizes up to 1600 A
- Switching capacities up to 150 kA and operational voltages up to 690 VAC can be managed without difficulty
- Extensive list of accessories for multiple installation options
- Several installation modes are optional
- Innovative switching technology with a double break contact system reduces clearing time
- In the event of a short circuit, the special shape and materials selected produce a repelling magnetic force that pushes the contacts apart in a fraction of a cycle
