Cutler-Hammer Series HM1R12

EATON HM1R12 Handle Mechanism, NEMA 1/3R/12 NEMA Rating, Rotary Handle Handle/Operation, Through-The-Door Handle Mounting, For Use With C Series F-Frame Molded Case Circuit Breaker, Molded Case Switch and Motor Circuit Protector
EATON HM1R12 Handle Mechanism, NEMA 1/3R/12 NEMA Rating, Rotary Handle Handle/Operation, Through-The-Door Handle Mounting, For Use With C Series F-Frame Molded Case Circuit Breaker, Molded Case Switch and Motor Circuit Protector

Cutler-Hammer Series HM1R12

EATON HM1R12 Handle Mechanism, NEMA 1/3R/12 NEMA Rating, Rotary Handle Handle/Operation, Through-The-Door Handle Mounting, For Use With C Series F-Frame Molded Case Circuit Breaker, Molded Case Switch and Motor Circuit Protector
Non-stock product. Available to order - lead time may vary.

BrandCutler-Hammer Series

MFG #HM1R12

Werner Part #588180

UPC786679165027

Non-stock product. Available to order - lead time may vary.

BrandCutler-Hammer Series

MFG #HM1R12

Werner Part #588180

UPC786679165027

Product Description

EATON Handle Mechanism, NEMA 1/3R/12, Rotary Handle, Through-The-Door Handle Mounting Position, For Use With: C Series F-Frame Molded Case Circuit Breaker, Molded Case Switch and Motor Circuit Protector, 12 in Shaft Length, Black, 4-1/2 x 19 x 9-1/4 in
Attributes
Actuator TypeHandle
Connection TypeLoad
Country of OriginUS
Dimensions4-1/2 x 19 x 9-1/4 in
Enclosure TypeNEMA AB1-1993
FrameF
Frequency Rating50/60 Hz
Interrupt Rating65/100 kA
ManufacturerEaton
Mounting TypePanel
NEMA RatingNEMA 1/3R/12
Number of Poles2
Phase1
SeriesC Series
Size of Wire14 to 1/0 AWG
Suitable For Use WithC Series F-Frame Molded Case Circuit Breaker, Molded Case Switch and Motor Circuit Protector
Temperature Rating40 deg C
Trip TypeFixed Thermal/Fixed Magnetic/Non-Interchangeable
TypeType HFD
