Cutler-Hammer Series HFD3030L
EATON HFD3030L C Series Type HFD Molded Case Circuit Breaker, 600 V AC/250 V DC, 30 A, 100 kAIC at 240 VAC/65 kAIC at 480 VAC Interrupt, 3 Poles, Thermal Magnetic Trip
Cutler-Hammer Series HFD3030L
EATON HFD3030L C Series Type HFD Molded Case Circuit Breaker, 600 V AC/250 V DC, 30 A, 100 kAIC at 240 VAC/65 kAIC at 480 VAC Interrupt, 3 Poles, Thermal Magnetic TripNon-stock product. Available to order - lead time may vary.
BrandCutler-Hammer Series
MFG #HFD3030L
Werner Part #1303181
UPC786679175095
Non-stock product. Available to order - lead time may vary.
BrandCutler-Hammer Series
MFG #HFD3030L
Werner Part #1303181
UPC786679175095
Product Description
EATON Molded Case Circuit Breaker, Type HFD, Series: C Series, 600 V AC/250 V DC, 30 A, 50/60 Hz, 100 kAIC at 240 VAC/65 kAIC at 480 VAC Interrupt, F Frame, Thermal Magnetic Trip, 3 Pole, 3 ph, Handle Actuator, Line/Load, 14 to 1/0 AWG Wire, NEMA AB1-1993, Panel Mount, 40 deg C, 3.38 x 4.13 x 6 in
Attributes
Documents
Applications
Features
Specifications
Attributes
Actuator TypeHandle
Connection TypeLine/Load
Country of OriginDO
Dimensions3.38 x 4.13 x 6 in
Enclosure TypeNEMA AB1-1993
FrameF
Frequency Rating50/60 Hz
Interrupt Rating100 kAIC at 240 VAC/65 kAIC at 480 VAC
ManufacturerEaton
Number of Poles3
Package TypeEACH
Phase3
SeriesC Series
Size of Wire14 to 1/0 AWG
Temperature Rating40 deg C
Trip TypeThermal Magnetic
TypeType HFD
Type / StyleType HFD
Voltage600 VAC/250 VDC
Documents
Applications
Panelboard, Switchboard, Motor Control Center and Busway Applications, Electrical Assemblies and OEMs
Features
- Patented contact design features high speed "blow-open" action, resulting in superior performance
- Suitable for reverse feed applications
- 100 kA at 240 VAC, 65 kA at 480 VAC interrupt rating
Specifications
14 to 8 Copper or 12 to 8 AWG Aluminum Solid Wire
