Cutler-Hammer Series HFD3020L

EATON HFD3020L C Series Type HFD Molded Case Circuit Breaker, 600 V AC/250 V DC, 20 A, 100 kAIC at 240 VAC/65 kAIC at 480 VAC Interrupt, 3 Poles, Thermal Magnetic Trip
EATON HFD3020L C Series Type HFD Molded Case Circuit Breaker, 600 V AC/250 V DC, 20 A, 100 kAIC at 240 VAC/65 kAIC at 480 VAC Interrupt, 3 Poles, Thermal Magnetic Trip

Cutler-Hammer Series HFD3020L

EATON HFD3020L C Series Type HFD Molded Case Circuit Breaker, 600 V AC/250 V DC, 20 A, 100 kAIC at 240 VAC/65 kAIC at 480 VAC Interrupt, 3 Poles, Thermal Magnetic Trip
Non-stock product. Available to order - lead time may vary.

BrandCutler-Hammer Series

MFG #HFD3020L

Werner Part #24794

UPC786679175071

Non-stock product. Available to order - lead time may vary.

BrandCutler-Hammer Series

MFG #HFD3020L

Werner Part #24794

UPC786679175071

Product Description

EATON Molded Case Circuit Breaker, Type HFD, Series: C Series, 600 V AC/250 V DC, 20 A, 50/60 Hz, 100 kAIC at 240 VAC/65 kAIC at 480 VAC Interrupt, F Frame, Thermal Magnetic Trip, 3 Pole, 3 ph, Handle Actuator, Line/Load, 14 to 1/0 AWG Wire, NEMA AB1-1993, Panel Mount, 40 deg C, 3.38 x 4.13 x 6 in
Attributes
Actuator TypeHandle
ColorBlack
Connection TypeLine/Load
Country of OriginDO
Dimensions3.38 x 4.13 x 6 in
Enclosure TypeNEMA AB1-1993
FinishTin Plated
FrameF
Frequency Rating50/60 Hz
Interrupt Rating100 kAIC at 240 VAC/65 kAIC at 480 VAC
ManufacturerEaton
MaterialAluminum/Thermoplastic
Number of Poles3
Phase3
Primary Connection/Pole1
Secondary Connection/Pole12
SeriesC Series
Short Circuit Current Rating100 kA
Size of Wire6 AWG to 350 kcmil Cu/AL Line, 14 to 4 AWG Cu, 12 to 4 AWG Al Load
Temperature Rating40 deg C
Trip TypeThermal Magnetic
TypeType HFD
Type / StyleType HFD
Voltage600 VAC/250 VDC
