Cutler-Hammer Series EGC3125FFG
EATON Cutler-Hammer Series EGC3125FFG Molded Case Circuit Breaker, 600Y/347 VAC, 125 A, 35/100/200 kA Interrupt, 3 Poles, Fixed Thermal/Fixed Magnetic Trip
Cutler-Hammer Series EGC3125FFG
EATON Cutler-Hammer Series EGC3125FFG Molded Case Circuit Breaker, 600Y/347 VAC, 125 A, 35/100/200 kA Interrupt, 3 Poles, Fixed Thermal/Fixed Magnetic TripNon-stock product. Available to order - lead time may vary.
BrandCutler-Hammer Series
MFG #EGC3125FFG
Werner Part #3843543
UPC786685140094
Non-stock product. Available to order - lead time may vary.
BrandCutler-Hammer Series
MFG #EGC3125FFG
Werner Part #3843543
UPC786685140094
Product Description
EATON Cutler-Hammer Series Molded Case Circuit Breaker, Series: G Series, 600Y/347 VAC, 125 A, 50/60 Hz Frequency, 35/100/200 kA Interrupt, EG Frame, Fixed Thermal/Fixed Magnetic Trip, 3 Pole, 3 ph, Toggle Actuator, Standard Line/Load Connection, 14 to 3/0 AWG, 14 to 1/0 AWG Wire, -20 to 70 deg C, 2.99 x 3 x 3 in Dimensions, Glass Polyester
Attributes
Documents
Features
Attributes
Actuator TypeToggle
Connection TypeStandard Line/Load
Country of OriginDominican Republic
Dimensions13 x 11.05 x 8.5 in
Enclosure TypeNEMA 3R/12
FrameEG
Frequency Rating45/66 Hz
Interrupt Rating35/100/200 kA
ManufacturerEaton
Number of Poles3
Phase3
Series6400
Size of Wire14 to 3/0 AWG, 14 to 1/0 AWG
Trip TypeFixed Thermal/Fixed Magnetic
TypeIQ Analyzer
Type / StyleComplete breaker
Voltage600Y/347 VAC
Documents
Features
Compact design frees up panel spaceCommon field fit internal accessories make installation and custom configuration easyAdvanced trip unit functionality offers a wide range of adjustment for maximum flexibilityPatented contact design features high speed "blow open" action, resulting in superior performanceMounting hardware and lugs are included for convenience, eliminating the need for separate parts ordersCircuit breakers significantly outperform the calculations listed in the institute of electrical and electronic engineers (IEEE) standard 1584-2002, guide for performing arc flash hazard calculationsMeets the requirements of UL, CSA, IEC, CCC and CE, providing a truly global design and worldwide acceptance14 to 3/0 AWG steel body, 14 to 1/0 AWG aluminum body wire size200 kA at 240 VAC, 100 kA at 415/480 VAC, 35 kA at 600Y/347 VAC interrupt rating
