Cutler-Hammer Series GHB3045
EATON Cutler-Hammer Series GHB3045 C Series Type GHB Molded Case Circuit Breaker, 277/480Y VAC/125/250 VDC, 45 A, 14/65 kA Interrupt, 3 Poles, Fixed Thermal/Fixed Magnetic/Non-Interchangeable Trip
Cutler-Hammer Series GHB3045
EATON Cutler-Hammer Series GHB3045 C Series Type GHB Molded Case Circuit Breaker, 277/480Y VAC/125/250 VDC, 45 A, 14/65 kA Interrupt, 3 Poles, Fixed Thermal/Fixed Magnetic/Non-Interchangeable TripNon-stock product. Available to order - lead time may vary.
Non-stock product. Available to order - lead time may vary.
Product Description
EATON Cutler-Hammer Series Molded Case Circuit Breaker, Type GHB, Series: C Series, 277/480Y VAC/125/250 VDC, 45 A, 50/60 Hz Frequency, 14/65 kA Interrupt, G Frame, Fixed Thermal/Fixed Magnetic/Non-Interchangeable Trip, 3 Pole, 3 ph, Line/Load Connection, 10 to 1/0 AWG Wire, NEMA AB1-1993 Enclosure, Bolt-On Mounting, 40 deg C, 2.63 in L x 3 in W x 4 in H Dimensions
Attributes
Documents
Features
Attributes
Connection TypeLine/Load
Country of OriginDominican Republic
Dimensions3.57 x 4.13 x 4.13 in
FrameJG
Frequency Rating50/60 Hz
Interrupt Rating25 kA
ManufacturerEaton
Number of Poles3
Package TypeEACH
SeriesG Series
Temperature Rating40 deg C
TypeType JGK
Documents
Features
Patented contact design features high speed "blow open" action, resulting in superior performance65 kA at 240 VAC, 14 kA at 480Y/277 VAC interrupt rating
