Bussmann Series BSPH2A24D24LVR
Bussmann easyID BSPH2A24D24LVR 1-Port Modular Surge Protective Device With Remote Signaling Contact, 25 A, 24/30 V AC/DC, 50/60 Hz, 2 Poles
Bussmann Series BSPH2A24D24LVR
Bussmann easyID BSPH2A24D24LVR 1-Port Modular Surge Protective Device With Remote Signaling Contact, 25 A, 24/30 V AC/DC, 50/60 Hz, 2 PolesNon-stock product. Available to order - lead time may vary.
BrandBussmann Series
MFG #BSPH2A24D24LVR
Werner Part #3935130
UPC051712358422
Non-stock product. Available to order - lead time may vary.
BrandBussmann Series
MFG #BSPH2A24D24LVR
Werner Part #3935130
UPC051712358422
Product Description
Bussmann easyID Surge Protective Device, 1-Port Modular, Series: BSPH, 25 A, 24/30 V AC/DC, 50/60 Hz, 2 Pole, 1 kA Nominal Discharge, Modes of Protection: L-N/L-N-G, 25 ns Response, Remote Indicator, Class: GL/GG/C, Environmental Conditions: -40 to 80 deg C Operating Temperature, IP20, DIN Rail Mount, Thermoplastic, 90 mm H x 18 mm W x 66 mm D
Attributes
Documents
Features
Warranty
Applications
Specifications
Attributes
ClassGL/GG/C
Country of OriginDE
Dimensions90 mm H x 18 mm W x 66 mm D
Electrical Ratings25 A, 24/30 V AC/DC
Enclosure TypeIP20
Environmental Conditions-40 to 80 deg C Operating Temperature
Frequency Rating50/60 Hz
IndicatorRemote
ManufacturerEaton
MaterialThermoplastic
Modes of ProtectionL-N/L-N-G
Mounting TypeDIN Rail
Nominal Discharge Current1 kA
Operating Temperature-40 To 80 Deg C
Response Time25 ns
SeriesBSPH
Type1-Port Modular
Type / StyleModular, With Remote Signaling Contact
Documents
Features
- Surge arrester according to UL 1449 4th edition, type 4 component assembly for use in type 3 applications helps meet UL 508A requirements
- "Thermodynamic control" SPD monitoring device ensures high reliability against surge events
- Module locking system with module release button makes module replacement easy without tools
- Proven MOV and GDT hybrid technology for reliable surge protection
- No upstream overcurrent protection necessary to make installation easier and more economical
- Vibration and shock tested according to EN 60068-2 to withstand harsh environments
Warranty
5 Years
Applications
Low Voltage Power and Control Systems
Specifications
Specifications: UL/CUL, CSA, KEMA
- Technology Type Hybrid, Number of Poles 2
Specifications: UL/CUL, CSA, KEMA
