Broan NuTone 509
Broan 509 Direct Discharge Through Wall Utility Ventilation Fan, 180 cfm, 8-3/8 in Dia Duct, 120 V AC, 1.5 A, Import
Broan NuTone 509
Broan 509 Direct Discharge Through Wall Utility Ventilation Fan, 180 cfm, 8-3/8 in Dia Duct, 120 V AC, 1.5 A, ImportNon-stock product. Available to order - lead time may vary.
Non-stock product. Available to order - lead time may vary.
Product Description
Broan Utility Ventilation Fan, Direct Discharge Through Wall, 180 cfm, 8-3/8 in Duct Dia, 120 V AC, 1.5 A, 60 Hz, 11-1/2 in Grille Length, 11-1/2 in Grille Width, Polymer Grille, 14-1/4 in Housing Width, 14-1/4 in Housing Height, Steel Housing, Wall Mount, No, White, Import
Attributes
Documents
Applications
Warranty
Features
Attributes
Air Flow Rate180 cfm
ColorWhite
Country of OriginMX
Domestic/ImportImport
Duct Diameter8-3/8 in
Flow Rate180 cfm
Frequency Rating60 Hz
Grille Length11-1/2 in
Grille MaterialPolymer
Grille SizeL: 11-1/2 in x W 10-5/8 in
Grille Width11-1/2 in
HeightHousing: 14-1/4 in
Housing MaterialSteel
Housing Width14-1/4 in
Humidity SensingNo
ManufacturerBroan-NuTone
Mounting TypeWall
TypeDirect Discharge Through Wall
Type / StyleDirect Discharge Through Wall
Voltage Rating120 V AC
WidthHousing: 14-1/4 in
Documents
Applications
For removing humidity from laundry rooms, tobacco smoke from rec rooms, fumes from workshops or cooking fumes from kitchens
Warranty
1 Year
Features
- Efficient ventilation for a variety of applications
- Contemporary styled grille complements modern decor
- White polymeric grilles can be painted to match any decor
- Permanently lubricated, thermally protected, plug-in motor
- Rugged steel housing with modern profile on outer weather hood
- Ventilator shall be steel housing finished with electrically bonded epoxy paint
- Specially designed polymeric fan blade
- Motor assembly offers fast, easy "twist-lock" installation
- Housing adjusts to fit walls from 4-1/2 to 9-1/2 in THK
- Built-in backdraft damper
- Long lasting electrically bonded epoxy coating can be painted to match outdoor styling
- Built-in rotary switch on model 509S no wall switch to wire
- 1925 rpm speed, 6.5 Sones sound level
- Eliminate humidity from laundry rooms, tobacco smoke from recreation rooms and workshops or cooking fumes from kitchens with Broans high efficiency utility ventilators
