NSi 8-350T4
NSI 8-350T4 Dual Rated Transformer Lug, 6 AWG to 350 kcmil, 3/8 in Stud, 4 Bolt Holes, Aluminum Alloy
NSi 8-350T4
NSI 8-350T4 Dual Rated Transformer Lug, 6 AWG to 350 kcmil, 3/8 in Stud, 4 Bolt Holes, Aluminum AlloyNon-stock product. Available to order - lead time may vary.
BrandNSi
MFG #8-350T4
Werner Part #4084367
UPC662381026941
Non-stock product. Available to order - lead time may vary.
BrandNSi
MFG #8-350T4
Werner Part #4084367
UPC662381026941
Product Description
NSI Transformer Lug, Dual Rated, Series: T Series, 6 AWG to 350 kcmil Conductor, 3/8 in Stud, 4 Bolt Holes, 600 V AC, Specifications: 1 Pole, 8 Conductor, 1-3/4 in Hole Spacing, 3/8 in Hole Dia, 3/8 in Wrench, 90 deg C, Aluminum Alloy, Electro-Tin Plated, 2.25 in L x 5.56 in W x 1.25 in H Dimensions
Attributes
Documents
Applications
Warranty
Features
Specifications
Attributes
Conductor size6 AWG to 350 kcmil
Country of OriginUS
Dimensions2.25 in L x 5.56 in W x 1.25 in H
FinishElectro-TiN Plated
ManufacturerNSi Industries
MaterialAluminum Alloy
Number of Bolt Holes4
SeriesT Series
Stud Size3/8 in
Temperature Rating90 deg C
TypeDual Rated
Type / StyleDual Rated
Voltage Rating600 V AC
Documents
Applications
For wire termination
Warranty
1 Year
Features
- Versatile and reusable set-screw connectors made from high strength 6061-T6 aluminum alloy for superior electrical and mechanical performance
- Two set-screws per wire hole ensure an exceptional connection
- Electro-tin plated for low contact resistance
Specifications
1 Pole, 8 Conductor, 1-3/4 in Hole Spacing, 3/8 in Hole Dia, 3/8 in Wrench
