Lithonia Lighting ECRG HO SQ M6
Lithonia Lighting Contractor Select Lithonia Lighting Basics ECRG HO SQ M6 Square Head Emergency Light/Exit Combo With Remote Capacity, 4 W Fixture, 120/277 V AC, White Housing, EXIT Legend
🚚 Ships Quickly from Acuity
Lithonia Lighting ECRG HO SQ M6
Lithonia Lighting Contractor Select Lithonia Lighting Basics ECRG HO SQ M6 Square Head Emergency Light/Exit Combo With Remote Capacity, 4 W Fixture, 120/277 V AC, White Housing, EXIT LegendNon-stock product. Available to order - lead time may vary.
BrandLithonia Lighting
MFG #ECRG HO SQ M6
Werner Part #4382567
UPC194994900504
Non-stock product. Available to order - lead time may vary.
BrandLithonia Lighting
MFG #ECRG HO SQ M6
Werner Part #4382567
UPC194994900504
Product Description
Lithonia Lighting Contractor Select Lithonia Lighting Basics Emergency Light/Exit Combo, Square Head, Series: ECRG Series, 120/277 V AC, 4 W Fixture, 0.03/0.02 A, 1 W Lamp, 2 Lamps, 2 Heads, 10 years Average Life, 6200 K Color, 75 CRI, EXIT Legend, Red/Green Legend, Surface Mount, 3.6 V NiMH Rechargeable Battery, Thermoplastic Housing, White Housing, 19.09 in W x 4.33 in D x 7.95 in H
Attributes
Documents
Applications
Features
Specifications
Warranty
Attributes
Average Life10 years
Color Rendering Index (CRI)75
Color Temperature6200 K
Country of OriginVN
Dimensions19.09 in W x 4.33 in D x 7.95 in H
Fixture Wattage4 W
Housing FinishWhite
Housing MaterialThermoplastic
Lamp TypeLED
Lamp Wattage1 W
LegendEXIT
ManufacturerAcuity Brands
Mounting TypeSurface
Number of Lamps2
Power Source3.6 V NiMH Rechargeable Battery
SeriesECRG Series
TypeSquare Head
Voltage Rating120/277 V AC
Documents
Applications
Education, Government, Healthcare, Hospitality, House of Worship, Retail, Offices and Banks
Features
- Contains ability to switch between red and green letters
- Features test switch and status indicator
- CUSTOMIZATION - The EXRG LED Exit Sign has an internal switch for red or green color selection
- HOUSING - Features bright white thermoplastic housing, fully assembled single-face exit comes with an extra faceplate and red and green panel inserts
- INSTALL / MOUNTING - Top, side and back mount options, Mounting pattern on canopy (top and side mount) and back plate (back mount) fits most standard size junction boxes
- DESIGN FEATURE - Provides a minimum of 90 min illumination for the rated wattage upon loss of AC power to meet code required emergency lighting
- BATTERY - 3.6V maintenance-free, rechargeable, nickel metal hydride
Specifications
- California Title 20
- FCC Certified
- NFPA 70/101
- OSHA Compliant
- UL 924
Warranty
2 years Limited
