Leviton BR20-I
Leviton BR20-I 1-Phase Duplex Heavy Duty Straight Blade Receptacle, 125 V AC, 20 A, 2 Poles, 3 Wires, Ivory
Leviton BR20-I
Leviton BR20-I 1-Phase Duplex Heavy Duty Straight Blade Receptacle, 125 V AC, 20 A, 2 Poles, 3 Wires, IvoryIn Stock: 158more info
|
BrandLeviton
MFG #BR20-I
Werner Part #46409
UPC078477819807
In Stock: 158more info
|
BrandLeviton
MFG #BR20-I
Werner Part #46409
UPC078477819807
Product Description
Leviton, BR20-I, Straight Blade Receptacle, 1-Phase Duplex Heavy Duty, 125 V AC, 20 A, 1 hp, 2 Pole, 3 Wires, NEMA 5-20R NEMA Rating, Commercial Grade, -40 to 60 deg C, Back/Side Wire Terminal, Nylon, Ivory, 46 in H x 1.56 in W x 19 in D Dimensions
Attributes
Documents
Applications
Features
Warranty
Specifications
Attributes
ColorIvory
ConnectionBack and Side Wired
Country of OriginUS
Dimensions46 in H x 1.56 in W x 19 in D
GradeCommercial
Horsepower1 hp
ManufacturerLeviton
MaterialNylon
NEMA RatingNEMA 5-20R
Number of Poles2
Number of Wires3
Phase1
Temperature Rating-40 to 60 deg C
Terminal TypeBack/Side Wire
Type1-Phase Duplex Heavy Duty
Type / StyleStraight Blade;Duplex Outlet
Voltage Rating125 V AC
Documents
Applications
Hotels, Schools, Hospitals and Commercial Office Buildings Applications
Features
- Manufactured to withstand the demands of commercial and institutional applications
- Heavy duty brass power contacts for maximum conductivity and plug retention
- Shallow design for maximum wiring room in box
- Self-grounding
- 2000 VAC minimum dielectric strength
- Narrow body
- Maximum 30 deg C after 250 cycles OL at 200% rated current temperature rise
- 14 to 10 AWG wire terminal
- Brass triple wipe 0.031 THK line contacts
- #10-32 brass terminal screws
Warranty
10 years
Specifications
Specifications: NEMA (WD-2, WD-1, WD-6);ANSI (C-73);NOM Certified (057);CSA C22.2 No. 42 (File 152105);UL Listed 498 (File E13399)
- Dielectric Strength: 2000 (Min.) V
Specifications: NEMA (WD-2, WD-1, WD-6);ANSI (C-73);NOM Certified (057);CSA C22.2 No. 42 (File 152105);UL Listed 498 (File E13399)
