Ferraz Shawmut MPDB68151
Mersen MPDB68151 Large Open Style Power Distribution Block, 600 V AC, 310 A, 1 Pole, 6 AWG to 350 kcmil Wire, Polycarbonate
Ferraz Shawmut MPDB68151
Mersen MPDB68151 Large Open Style Power Distribution Block, 600 V AC, 310 A, 1 Pole, 6 AWG to 350 kcmil Wire, PolycarbonateIn Stock: 3more info
|
BrandFerraz Shawmut
MFG #MPDB68151
Werner Part #4130691
UPC782001455279
In Stock: 3more info
|
BrandFerraz Shawmut
MFG #MPDB68151
Werner Part #4130691
UPC782001455279
Product Description
Mersen Power Distribution Block, Large Open Style, Series: MPDB, 600 V AC, 310 A, 1 Pole, 1 Primary Connections/Pole, 12 Secondary Connection/Pole, 6 AWG to 350 kcmil Wire, 100 kA Short Circuit Current, Polycarbonate, Black, 3.55 in H x 2.73 in W x 5.7 in D
Attributes
Documents
Applications
Features
Attributes
Breaker TypeMBK100A
ColorBlack
Country of OriginMX
Dimensions3.55 in H x 2.73 in W x 5.7 in D
Enclosure TypeNEMA 3R
Interrupt Rating100 kA
ManufacturerMERSEN
MaterialPolycarbonate
Mounting TypeSurface
Number of Circuits20
Number of Poles1
Number of Spaces4
Primary Connection/Pole1
Secondary Connection/Pole12
SeriesMPDB
Short Circuit Current Rating100 kA
TypeLarge Open Style
Wiring Configuration3-Wire
Documents
Applications
Cable Splicing, Splitting Primary Power into Secondary Circuits, Fixed Junction Tap-Off Points
Features
- Aluminum connectors accept both aluminum or copper wire while copper connectors accept copper wire only
- Connectors are all 1-piece tin plated
- Insulators are virtually unbreakable, made of glass-filled polycarbonate
- See-through, hinged safety covers provide a greater degree of safety and shock resistance where required
- Hinged covers can be installed without tools
- 1 in through air and 2 in over surface between uninsulated live parts of opposite polarity meets requirements for feeder and branch circuit applications of UL 508A
- Polycarbonate safety covers provide dead-front protection
- One cover is needed for each pole
- Each cover has a test probe hole in the center for circuit checking
- 6 AWG to 350 kcmil Cu line, 14 to 4 AWG Cu load
