nVent HOFFMAN A12R124
Hoffman A12R124 A Style Body Enclosure With Knockout, 12 in H x 12 in W x 4 in D, Screw Cover, NEMA 3R/IP32 NEMA Rating, Steel
nVent HOFFMAN A12R124
Hoffman A12R124 A Style Body Enclosure With Knockout, 12 in H x 12 in W x 4 in D, Screw Cover, NEMA 3R/IP32 NEMA Rating, SteelIn Stock: 1more info
|
BrandnVent HOFFMAN
MFG #A12R124
Werner Part #35371
UPC783510380809
In Stock: 1more info
|
BrandnVent HOFFMAN
MFG #A12R124
Werner Part #35371
UPC783510380809
Product Description
Hoffman Enclosure, A Style Body, Series: A90S3, 12 in Height, 12 in Width, 4 in Depth, NEMA 3R/IP32 NEMA Rating, Screw Cover, Lock: Padlock, (2) 3/4 to 1 in, (2) 1/2 to 3/4 in, (1) 1 to 1-1/4 in Knockout Bottom Cable Entry, Wall Mounting, Steel, Galvanized, Gray
Attributes
Documents
Applications
Features
Specifications
Attributes
Cable Entry Size(2) 3/4 to 1 in, (2) 1/2 to 3/4 in, (1) 1 to 1-1/4 in Knockout Bottom
ColorGray
Country of OriginMX
Cover TypeScrew
FinishGalvanized
ManufacturernVent
MaterialSteel
Mounting TypeWall
NEMA RatingNEMA 3R/IP32
Package Height4.3 in
Package Length12 in
Package TypePIECE
Package Volume656.64 cu-in
Package Weight10 lb
Package Width12 in
SeriesA90S3
Size12 in H
TypeA Style Body
Type / StyleA Style Body
Documents
Applications
For outdoor application as a wiring or junction box
Features
- Drip shield top and seam-free sides, front, and back protect from rain, snow, or sleet
- Slip-on removable cover fastened with plated steel screws along bottom edge
- Handles on larger sizes (see table)
- Embossed mounting holes on back of enclosure
- Knockouts in bottom of 16 and 14 ga enclosures
- Provision for padlocking
- No gasketing
- Enclosures are finished with paint over plated surfaces
- Top and bottom thickness gauge is the same as the body thickness gauge unless otherwise noted in table
Specifications
Padlock
