Bussmann Series HCTR25
Edison HCTR25 Current Limiting Time Delay Fuse, 25 A, 600 V AC, 200 kA, Class CC
Bussmann Series HCTR25
Edison HCTR25 Current Limiting Time Delay Fuse, 25 A, 600 V AC, 200 kA, Class CCNon-stock product. Available to order - lead time may vary.
BrandBussmann Series
MFG #HCTR25
Werner Part #3910376
UPC782634839002
Non-stock product. Available to order - lead time may vary.
BrandBussmann Series
MFG #HCTR25
Werner Part #3910376
UPC782634839002
Product Description
Edison Time Delay Fuse, Current Limiting, Series: HCTR, Rejection/Non-Rejection: Rejection, 25 A, 600 V AC, 200 kA Interrupt, Class: CC, Ferrule Terminal, Dual Element, Melamine, 0.41 in Dia x 1.5 in L Body Size
Attributes
Documents
Applications
Features
Attributes
Body Size0.41 in Dia x 1.5 in L
ClassCC
Country of OriginMX
ElementDual
Interrupt Rating200 kA
ManufacturerEaton
MaterialMelamine
Package Height0.41 in
Package Length1.5 in
Package TypeEACH
Package Width0.41 in
Rejection/Non-RejectionRejection
SeriesHCTR
Terminal TypeFerrule
Type / StyleCurrent Limiting
Voltage Rating600 V AC
Applications
PH Series Primary Control Power Transformers Protection Applications
Features
- The HCTR was designed to meet the needs of control circuit transformer protection
- Current limitation protects down stream components against damaging thermal and magnetic effects of short circuit currents
- HCTR fuses meet the UL 508, paragraph 19.2.4 requirement that control circuit fuses used in equipment listed for use with more than 10 kA available must have an adequate interrupt rating and must be rejection type
- High inrush time delay
- Control circuit transformers can experience inrush currents up to 85 times their full load current rating
- HCTR fuses can be sized according to NEC and UL requirements and still allow the high inrush currents, with significantly more time delay than the UL minimum value of 12 sec at 200% for class CC fuses
- Melamine tube with nickel plated bronze endcap
