Southwire 55979101
Southwire 55979101 Type MCAP HCF Armor Cable, coil Packaging, 600 V AC, (3) 12 AWG Stranded Copper Conductor, 250 ft L
Southwire 55979101
Southwire 55979101 Type MCAP HCF Armor Cable, coil Packaging, 600 V AC, (3) 12 AWG Stranded Copper Conductor, 250 ft LNon-stock product. Available to order - lead time may vary.
BrandSouthwire
MFG #55979101
Werner Part #4039254
UPC032886099014
Non-stock product. Available to order - lead time may vary.
BrandSouthwire
MFG #55979101
Werner Part #4039254
UPC032886099014
Product Description
Southwire Armor Cable, Type MCAP HCF, coil Packaging, 600 V AC, 3 Conductors, Stranded Copper Conductor, 12 AWG Conductor, 0.5056 in OD, 250 ft Length, PVC Insulation, Brown/Gray/Green/Orange Jacket, 90 deg C
Attributes
Documents
Applications
Warranty
Features
Specifications
Attributes
BABA CompliantYes
Conductor size12 AWG
Conductor TypeStranded Copper
Country of OriginUS
Insulation MaterialPVC
Jacket ColorBrown/Gray/Green/Orange
ManufacturerSouthwire Company
Number of Conductors3
Outside Diameter0.5056 in
Packaging TypeCoil
Temperature Rating90 deg C
TypeType MCAP HCF
Voltage Rating600 V AC
Documents
Applications
Hospital Care Facility, General Purpose, Non-Essential Electrical Systems In Patient Care Areas of Hospitals, Medical and Other Health Care Facilities Applications
Warranty
1 Year
Features
- Such areas include nursing homes, dental offices, clinics, and outpatient facilities
- Use in hazardous anesthetizing areas is prohibited
- The thermoplastic jacket and conduit is rated for extreme hot and cold temperature environments
- Fished or embedded in plaster
- Concealed or exposed installations
Specifications
Standards/Approvals: ARRA Compliant|Buy American Act Compliant|RoHS Compliant|UL 83/1569/1063|NFPA 70|NEC Article 330|Federal Specification A-A59544 (formerly J-C-30B)|IEEE 1202 (70,000 Btu/hr) Vertical Cable Tray Flame Test|UL 1, 2, and 3 Hour Through-Penetration Firestop Systems|REACH Compliant
