Southwire 55654989
Southwire SIMpull 55654989 Type THHN/THWN-2/MTW Building Wire, 600 V AC, 500 kcmil Copper Conductor, Green
Southwire 55654989
Southwire SIMpull 55654989 Type THHN/THWN-2/MTW Building Wire, 600 V AC, 500 kcmil Copper Conductor, GreenOut of Stockmore info
|
BrandSouthwire
MFG #55654989
Werner Part #1326502
UPC032886841774
Out of Stockmore info
|
BrandSouthwire
MFG #55654989
Werner Part #1326502
UPC032886841774
Product Description
Southwire SIMpull Building Wire, Type THHN/THWN-2/MTW, 600 V AC, 430 A, Copper Conductor, 500 kcmil Conductor, 926 mil OD, 37 Strands, PVC Insulation, Nylon Jacket, Green Jacket, 60/75/90 deg C
Attributes
Applications
Warranty
Features
Specifications
Attributes
Conductor size500 kcmil
Conductor TypeCopper
Country of OriginCN
Insulation MaterialPVC
Jacket ColorGREEN
Jacket MaterialNylon
ManufacturerSouthwire Company
Outside Diameter926 mil
Strands37
Temperature Rating60/75/90 deg C
TypeType THHN/THWN-2/MTW
Voltage Rating600 V AC
Applications
For used in conduit and cable trays for services, feeders and branch circuit in commercial or industrial applications
Warranty
1 Year
Features
- Heat, moisture, gasoline and oil-resistant
- SIMpull THHN copper conductors are designed to be installed without application of a pulling lubricant
- 320 A at 60 deg C for MTW, 380 A at 75 deg C for THWN, 430 A at 90 deg C for THHN
- THHN or T90 nylon- dry locations not to exceed 90 deg C
- THWN-2- wet or dry locations not to exceed 90 deg C or locations not to exceed 75 deg C when exposed to oil
- MTW- wet locations or when exposed to oil at temperatures not to exceed 60 deg C or dry locations not to exceed 90 deg C (with ampacity limited to that for 75 deg C conductor temperature per NFPA 79)
- CT rated in sizes 1/0 AWG and larger
Specifications
Standards/Approvals: cULs Listed, ASTM B3, B8 and B787 Standard, UL 83, 758, 1063 and 1581 Listed, Federal Specification A-A-59544, NEMA WC-70, NEC NFPA 70, RoHS/REACH Compliant
