Southwire 55618089
Southwire SIMpull 55618089 Type THHN/THWN-2/MTW Building Wire, 600 V AC, 600 kcmil Copper Conductor, Orange
Southwire 55618089
Southwire SIMpull 55618089 Type THHN/THWN-2/MTW Building Wire, 600 V AC, 600 kcmil Copper Conductor, OrangeIn Stock: 22440more info
|
BrandSouthwire
MFG #55618089
Werner Part #1412197
UPC032886841859
In Stock: 22440more info
|
BrandSouthwire
MFG #55618089
Werner Part #1412197
UPC032886841859
Product Description
Southwire SIMpull Building Wire, Type THHN/THWN-2/MTW, 600 V AC, 475 A, Copper Conductor, 600 kcmil Conductor, 1024 mil OD, 61 Strands, PVC Insulation, Nylon Jacket, Orange Jacket, 60/75/90 deg C
Attributes
Applications
Features
Specifications
Warranty
Attributes
BABA CompliantYes
Conductor size600 kcmil
Conductor TypeCopper
Country of OriginUS
Insulation MaterialPVC
Jacket ColorOrange
Jacket MaterialNylon
ManufacturerSouthwire Company
Outside Diameter1024 mil
Package Weight1987 lb
Strands61
Temperature Rating60/75/90 deg C
TypeType THHN/THWN-2/MTW
Voltage Rating600 V AC
Applications
For used in conduit and cable trays for services, feeders and branch circuit in commercial or industrial applications
Features
- Heat, moisture, gasoline and oil-resistant
- SIMpull THHN copper conductors are designed to be installed without application of a pulling lubricant
- 350 A at 60 deg C for MTW, 420 A at 75 deg C for THWN, 475 A at 90 deg C for THHN
- THHN or T90 nylon- dry locations not to exceed 90 deg C
- THWN-2- wet or dry locations not to exceed 90 deg C or locations not to exceed 75 deg C when exposed to oil
- MTW- wet locations or when exposed to oil at temperatures not to exceed 60 deg C or dry locations not to exceed 90 deg C (with ampacity limited to that for 75 deg C conductor temperature per NFPA 79)
- CT rated in sizes 1/0 AWG and larger
Specifications
Standards/Approvals: cULs Listed, ASTM B3, B8 and B787 Standard, UL 83, 758, 1063 and 1581 Listed, Federal Specification A-A-59544, NEMA WC-70, NEC NFPA 70, RoHS/REACH Compliant
Warranty
1 Year
