Advance IZT3PSP32SC35I
Advance Mark 7 0-10V IZT3PSP32SC35I Controllable Electronic Linear Small Can Dimmable Fluorescent Ballast, T8 Lamp, 32 W, 120 to 277 V AC, Programmed/Rapid, 0.88 Ballast Factor
Advance IZT3PSP32SC35I
Advance Mark 7 0-10V IZT3PSP32SC35I Controllable Electronic Linear Small Can Dimmable Fluorescent Ballast, T8 Lamp, 32 W, 120 to 277 V AC, Programmed/Rapid, 0.88 Ballast FactorNon-stock product. Available to order - lead time may vary.
BrandAdvance
MFG #IZT3PSP32SC35I
Werner Part #4049236
UPC781087135396
Non-stock product. Available to order - lead time may vary.
BrandAdvance
MFG #IZT3PSP32SC35I
Werner Part #4049236
UPC781087135396
Product Description
Advance Mark 7 0-10V Dimmable Fluorescent Ballast, Controllable Electronic Linear Small Can, T8 Lamp, 32 W Lamp, 16 to 94 W Wattage, 120 to 277 V AC, 0.33 to 0.79 A, 50/60 Hz Frequency, Programmed/Rapid Start, 50 deg F Minimum Starting, Total Harmonic Distortion: 10%, Power Factor: 0.88, Yes Dimmable, 3 Lamps, Thermal Protection: Class P, Ballast Factor: 0.88, 70 deg C, Metal, 9.5 in L x 1.7 in W x 1.18 in H Dimensions
Attributes
Documents
Applications
Warranty
Features
Attributes
Ballast Factor0.88
Country of OriginMX
Dimensions9.5 in L x 1.7 in W x 1.18 in H
DimmableYes
Frequency Rating50/60 Hz
Lamp TypeT8
Lamp Wattage32 W
ManufacturerSignify
MaterialMetal
Number of Lamps3
Package Height1.28 in
Package Length9.5 in
Package TypeEACH
Package Weight1 lb
Package Width2.4 IN
Power Factor0.88
Start TypeProgrammed/Rapid
Temperature Range70 deg C
Thermal ProtectionClass P
Total Harmonic Distortion10%
TypeControllable Electronic Linear Small Can
Type / StyleControllable Electronic Linear Small Can
Voltage Rating120 to 277 V AC
Wattage16 to 94 W
Applications
Lighting Luminaire Component, TV, Radio Station, Library, Reception, Reading Room, Church and School Study Hall Applications
Warranty
5 years
Features
- IntelliVolt multiple voltage technology enables operation from 120 to 277 VAC, 50/60 Hz
- Philips Advance fluorescent electronic and magnetic ballasts are designed and manufactured to engineering standards correlating to an average life expectancy of 50000 hr of operation at maximum rated case temperature
- Blue label color coding
- 20 to 24 dB average ambient noise level of interior
- High power factor
- Sound rated A
- Programmed start parallel lamp connection
- 35I - ballast individual packaged
- Provides task appropriate comfort only where necessary to increase potential energy savings while supporting LEED performance standards
- Full range continuous dimming (100% light output down to 3% - T5HO to 1%)
- Help reduce maintece costs as more lamps remain on when lamps reach end of life minimizing wasteful re-lamping
- Independent light operation (4-lamp)
- 0 to 10 VDC electronic dimming ballasts provide maximum versatility with low voltage dimming
- Automatic restart
- 1.6 nominal crest factor
- 1.5 s nominal ignition time
- 18 AWG solid wire
