Panduit STP6X1BU
Panduit STP6X1BU Shielded Patch Cord, Cat 6a, 26 AWG 4-Pair S/FTP Stranded Copper Conductor, 8-Position TX6A 10Gig Modular Plug Connector, 1 ft L Cord, Blue Cable/Black Boot
Panduit STP6X1BU
Panduit STP6X1BU Shielded Patch Cord, Cat 6a, 26 AWG 4-Pair S/FTP Stranded Copper Conductor, 8-Position TX6A 10Gig Modular Plug Connector, 1 ft L Cord, Blue Cable/Black BootIn Stock: 22more info
|
BrandPanduit
MFG #STP6X1BU
Werner Part #4055593
UPC074983475575
In Stock: 22more info
|
BrandPanduit
MFG #STP6X1BU
Werner Part #4055593
UPC074983475575
Product Description
Panduit Patch Cord, Shielded, Category: Cat 6a, 26 AWG Conductor, 4-Pair S/FTP Stranded Copper Conductor, 8-Position TX6A 10Gig Modular Plug Connector, 1 ft Cord Length, Blue Cable/Black Boot, 14 to 140 deg F
Attributes
Documents
Applications
Features
Attributes
Category TypeCat 6a
ColorBlue Cable/Black Boot
Conductor size26 AWG
Conductor Type4-Pair S/FTP Stranded Copper
Connector Type8-Position TX6A 10Gig Modular Plug
Cord Length1 ft
ManufacturerPanduit
Temperature Rating14 to 140 deg F
TypeShielded
Type / StyleShielded
Documents
Applications
Stacking Switched and Switch-To-Switch Links, Aggregation of Gigabit Ethernet Channels, Streaming Video, Scientific Modeling, Storage Area Networks, Real-Time Intensive Financial Transactions, Animation and Medical Imaging
Features
- 100% performance tested for wire map, next and return loss
- Centered de-embedded plug performs in center of ANSI/TIA-568-C.2 component range, ensuring interoperability and optimum performance
- Integral pair manager optimizes performance and consistency by reducing untwist at plug
- Patented tangle free latch prevents snags and provides easy release, saving time on frequent moves, adds and changes
- Slender strain relief boot provides easy access in high density applications
- Provides identification of performance level, length and quality control number for future traceability
- Rated to 2500 mating cycles
- 10 Gb/s patch cord
- Aluminum cable shield
- Plated cartridge brass plug shield
- -40 to 70 deg C storage temperature
- Polycarbonate plug
- CM/LSZH dual rated flammability
- 0.24 in nominal outer diameter cable
- TPE boot
