Panduit SCS500-6
Panduit Pan-Lug SCS500-6 Compression Butt Splice, 500 kcmil Conductor, 2.87 in L, Standard Barrel, Copper, Brown
Panduit SCS500-6
Panduit Pan-Lug SCS500-6 Compression Butt Splice, 500 kcmil Conductor, 2.87 in L, Standard Barrel, Copper, BrownNon-stock product. Available to order - lead time may vary.
BrandPanduit
MFG #SCS500-6
Werner Part #1103909
UPC074983903658
Non-stock product. Available to order - lead time may vary.
BrandPanduit
MFG #SCS500-6
Werner Part #1103909
UPC074983903658
Product Description
Panduit Pan-Lug Compression Butt Splice, Series: SCS, Stranded Copper Conductor, 500 kcmil Conductor, 2.87 in Length, Standard Barrel, 0.84 in ID x 1.05 in OD Barrel, 35 kV, 1-3/8 in L Wire Strip, 90 deg C, Copper, Brown, Electro TiN Coated
Attributes
Documents
Applications
Features
Specifications
Attributes
Barrel Size0.84 in ID x 1.05 in OD
Barrel TypeStandard
ColorBrown
Conductor size500 kcmil
Conductor TypeStranded Copper
Country of OriginMX
FinishElectro TiN Coated
ManufacturerPanduit
MaterialCopper
SeriesSCS
Temperature Rating90 deg C
TypeType SCS
Type / StyleCompression
Voltage Rating35 kV
Documents
Applications
For wide wire range taking capability when crimped with Panduit Uni-Die dieless crimping tools
Features
- Color-coded barrels marked with Panduit and specified competitor die index numbers for proper crimp die selection
- Internal solid center prevents over-insertion of conductor
- Tin plated to inhibit corrosion
- Color coded barrels marked with Panduit and specified competitor die index numbers for proper crimp die selection
- Internal wire stops to prevent over insertion of conductor
- Tin plated to inhibit corrosion
- UL listed and CSA certified to 35 kV and temperature rated to 90 deg C when crimped with Panduit and specified competitor crimping tools and dies
Specifications
1-3/8 in L Wire Strip
