Panduit LCC500-12W-6
Panduit Pan-Lug LCC500-12W-6 LCC-W 2-Hole Compression Lug Connector With Inspection Window, 500 kcmil Stranded Copper Conductor, Die Code: P87, 1/2 in Stud, Tin Plated Copper
Panduit LCC500-12W-6
Panduit Pan-Lug LCC500-12W-6 LCC-W 2-Hole Compression Lug Connector With Inspection Window, 500 kcmil Stranded Copper Conductor, Die Code: P87, 1/2 in Stud, Tin Plated CopperIn Stock: 9more info
|
BrandPanduit
MFG #LCC500-12W-6
Werner Part #1520736
UPC074983798513
In Stock: 9more info
|
BrandPanduit
MFG #LCC500-12W-6
Werner Part #1520736
UPC074983798513
Product Description
Panduit Pan-Lug Compression Lug Connector, 2-Hole, Series: LCC-W, Stranded Copper Conductor, 500 kcmil Conductor, Die Code: P87, 35 kV, 1/2 in Stud, Straight Tongue, 1.54 in W x 0.22 in THK Tongue, 6.12 in Overall Length, Long/Inspection Window Barrel, 0.84 in ID x 1.06 in OD x 2.5 in L Barrel, Specifications: 1-3/4 in Stud Hole Spacing, 2-9/16 in L Wire Strip, Tin Plated, 90 deg C, 2-9/16 in Mounting Hole, Tin Plated Copper, Brown
Attributes
Documents
Applications
Features
Specifications
Attributes
Barrel Size0.84 in ID x 1.06 in OD x 2.5 in L
Barrel TypeLong/Inspection Window
ColorBrown
Conductor size500 kcmil
Conductor TypeStranded Copper
Country of OriginMX
Die CodeP87
ManufacturerPanduit
MaterialTin Plated Copper
Mounting Hole Type2-9/16 in
Overall Length6.12 in
Package Height3.3 in
Package Length7.85 IN
Package Volume158257 cu-in
Package Weight3.88 lb
Package Width3.4 in
SeriesLCC-W
Stud Size1/2 in
Temperature Rating90 deg C
Tongue Size1.54 in W x 0.22 in THK
Tongue TypeStraight
Type2-Hole
Type / Style2-Hole
Voltage Rating35 kV
Documents
Applications
For use with stranded copper conductors
Features
- The long barrel maximizes the number of crimps and provides premium wire pullout strength and performance
- Inspection window to visually assure full conductor insertion
- color-coded barrel marked with Panduit and specified competitor die index numbers for proper crimp die selection
- Tin-plated to inhibit corrosion
- For use with stranded copper conductor
- Consult cable manufacturer for voltage stress relief instructions with application greater than 2000 V
- The generously beveled wire entry prevents bent back strands when inserting the conductor into the barrel
- Long barrel maximizes the number of crimps and provides premium wire pullout strength and electrical performance
- Inspection window to visually assure full conductor insertion
- Color coded barrels marked with Panduit and specified competitor die index numbers for proper crimp die selection
- Tin plated to inhibit corrosion
Specifications
1-3/4 in Stud Hole Spacing, 2-9/16 in L Wire Strip, Tin Plated
