Panduit LCC4-12W-L
Panduit Pan-Lug LCC4-12W-L 2-Hole Compression Lug, 4 AWG Stranded Copper Conductor, Die Code: P29, 42.767 in Stud, Copper
Panduit LCC4-12W-L
Panduit Pan-Lug LCC4-12W-L 2-Hole Compression Lug, 4 AWG Stranded Copper Conductor, Die Code: P29, 42.767 in Stud, CopperNon-stock product. Available to order - lead time may vary.
BrandPanduit
MFG #LCC4-12W-L
Werner Part #3978267
UPC074983797820
Non-stock product. Available to order - lead time may vary.
BrandPanduit
MFG #LCC4-12W-L
Werner Part #3978267
UPC074983797820
Product Description
Panduit Pan-Lug Compression Lug, 2-Hole, Series: LCC-W, Stranded Copper Conductor, 4 AWG Conductor, Die Code: P29, 35 kV, 42.767 in Stud, Straight Tongue, 3/4 in W x 5/64 in THK Tongue, 4.01 in Overall Length, Long/Inspection Window Barrel, 0.28 in ID x 0.38 in OD x 1.05 in L Barrel, Specifications: 1-1/8 in L Wire Strip, 1-3/4 in Stud Hole Spacing, Tin Plated Finish, 90 deg C, 1.13 in Mounting Hole, Copper, Gray
Attributes
Documents
Features
Specifications
Attributes
Barrel Size0.28 in ID x 0.38 in OD x 1.05 in L
Barrel TypeLong/Inspection Window
ColorGray
Conductor size4 AWG
Conductor TypeStranded Copper
Country of OriginMX
Die CodeP29
ManufacturerPanduit
MaterialCopper
Mounting Hole Type1.13 in
Overall Length4.01 in
SeriesLCC-W
Stud Size42.767 in
Temperature Rating90 deg C
Tongue Size3/4 in W x 5/64 in THK
Tongue TypeStraight
Type2-Hole
Type / Style2-Hole
Voltage Rating35 kV
Documents
Features
- Long barrel maximizes number of crimps and provides premium wire pull-out strength and electrical performance
- Inspection window to visually assure full conductor insertion
- Color-coded barrels marked with Panduit and specified competitor die index numbers for proper crimp die selection
- Tin-plated to inhibit corrosion
- For use with stranded copper conductors
- Consult cable manufacturer for voltage stress relief instructions with applications greater than 2000 V
- Long barrel maximizes number of crimps and provides premium wire pull out strength and electrical performance
- Inspection window to visually assure full conductor insertion
- Color coded barrels marked with Panduit and specified competitor die index numbers for proper crimp die selection
- Tin plated to inhibit corrosion
- UL listed and CSA certified to 35 kV and temperature rated to 90 deg C when crimped with Panduit and specified competitor crimping tools and dies
- 4 to 3 AWG stranded, 2 AWG solid conductor
Specifications
1-1/8 in L Wire Strip, 1-3/4 in Stud Hole Spacing, Tin Plated Finish
