Panduit LCC4/0-38DW-X
Panduit Pan-Lug LCC4/0-38DW-X LCC-W 2-Hole Compression Connector Lug, 4/0 AWG Stranded Copper Conductor, Die Code: P54, 3/8 in Stud, Tin Plated Copper
Panduit LCC4/0-38DW-X
Panduit Pan-Lug LCC4/0-38DW-X LCC-W 2-Hole Compression Connector Lug, 4/0 AWG Stranded Copper Conductor, Die Code: P54, 3/8 in Stud, Tin Plated CopperNon-stock product. Available to order - lead time may vary.
BrandPanduit
MFG #LCC4/0-38DW-X
Werner Part #1102920
UPC074983798339
Non-stock product. Available to order - lead time may vary.
BrandPanduit
MFG #LCC4/0-38DW-X
Werner Part #1102920
UPC074983798339
Product Description
Panduit Pan-Lug Compression Connector Lug, 2-Hole, Series: LCC-W, Stranded Copper Conductor, 4/0 AWG Conductor, Die Code: P54, 35 kV, 3/8 in Stud, Straight Tongue, 1.06 in W x 0.14 in THK Tongue, 3.81 in Overall Length, Long Barrel, 0.57 in ID x 0.71 in OD x 1.56 in L Barrel, 1 in Stud Hole Spacing, 1-5/8 in L Wire Strip, 90 deg C, 1.63 in Mounting Hole, Tin Plated Copper, Purple
Attributes
Documents
Applications
Features
Specifications
Attributes
Barrel Size0.57 in ID x 0.71 in OD x 1.56 in L
Barrel TypeLong
ColorPurple
Conductor size4/0 AWG
Conductor TypeStranded Copper
Country of OriginMX
Die CodeP54
ManufacturerPanduit
MaterialTin Plated Copper
Mounting Hole Type1.63 in
Overall Length3.81 in
Package Height3.4 IN
Package Length4.8 IN
Package Volume119439 cu-in
Package Weight1.86 lb
Package Width3.4 in
SeriesLCC-W
Stud Size3/8 in
Temperature Rating90 deg C
Tongue Size1.06 in W x 0.14 in THK
Tongue TypeStraight
Type2-Hole
Type / Style2-Hole
Voltage Rating35 kV
Documents
Applications
Power and Grounding Applications
Features
- Long barrel maximizes number of crimps and provides premium wire pull-out strength and electrical performance
- Inspection window to visually assure full conductor insertion
- Color-coded barrels marked with Panduit and specified competitor die index numbers for proper crimp die selection
- Tin plated to inhibit corrosion
- For use with stranded copper conductors
- Consult cable manufacturer for voltage stress relief instructions with applications greater than 2000 V
- Long barrel maximizes number of crimps and provides premium wire pull-out strength and electrical performance
- Inspection window to visually assure full conductor insertion
- Color-coded barrels marked with Panduit and specified competitor die index numbers for proper crimp die selection
- Tin-plated to inhibit corrosion
- UL listed and CSA certified to 35 kV and temperature rated to 90 deg C when crimped with Panduit and specified competitor crimping tools and dies
- Meets J-STD-607-A and TIA-942 requirements for network systems grounding applications
- Consult cable manufacturer for voltage stress relief instructions with applications greater than 2000 V
Specifications
1 in Stud Hole Spacing, 1-5/8 in L Wire Strip
