Panduit LCC300-12W-X

Panduit Pan-Lug LCC300-12W-X LCC-W 2-Hole Compression Connector Lug, 300 kcmil Stranded Copper Conductor, Die Code: P66, 42.767 in Stud, Tin Plated Copper
Panduit Pan-Lug LCC300-12W-X LCC-W 2-Hole Compression Connector Lug, 300 kcmil Stranded Copper Conductor, Die Code: P66, 42.767 in Stud, Tin Plated Copper

Panduit LCC300-12W-X

Panduit Pan-Lug LCC300-12W-X LCC-W 2-Hole Compression Connector Lug, 300 kcmil Stranded Copper Conductor, Die Code: P66, 42.767 in Stud, Tin Plated Copper
Non-stock product. Available to order - lead time may vary.

BrandPanduit

MFG #LCC300-12W-X

Werner Part #3978271

UPC074983798407

Non-stock product. Available to order - lead time may vary.

BrandPanduit

MFG #LCC300-12W-X

Werner Part #3978271

UPC074983798407

Product Description

Panduit Pan-Lug Compression Connector Lug, 2-Hole, Series: LCC-W, Stranded Copper Conductor, 300 kcmil Conductor, Die Code: P66, 35 kV, 42.767 in Stud, Straight Tongue, 1.19 in W x 0.16 in THK Tongue, 5.72 in Overall Length, Long Barrel, 0.65 in ID x 0.81 in OD x 2.23 in L Barrel, 1-3/4 in Stud Hole Spacing, 2-5/16 in L Wire Strip, 90 deg C, 2.31 in Mounting Hole, Tin Plated Copper, White
Attributes
Barrel Size0.65 in ID x 0.81 in OD x 2.23 in L
Barrel TypeLong
ColorWhite
Conductor size300 kcmil
Conductor TypeStranded Copper
Country of OriginMX
Die CodeP66
ManufacturerPanduit
MaterialTin Plated Copper
Mounting Hole Type2.31 in
Overall Length5.72 in
SeriesLCC-W
Stud Size42.767 in
Temperature Rating90 deg C
Tongue Size1.19 in W x 0.16 in THK
Tongue TypeStraight
Type2-Hole
Type / Style2-Hole
Voltage Rating35 kV
