Panduit LCBX250-12-X
Panduit Pan-Lug LCBX250-12-X 1-Hole Compression Lug, 250 kcmil, 262.6 kcmil Flexible Copper Conductor, Die Code: P62, 42.767 in Stud, Copper
Panduit LCBX250-12-X
Panduit Pan-Lug LCBX250-12-X 1-Hole Compression Lug, 250 kcmil, 262.6 kcmil Flexible Copper Conductor, Die Code: P62, 42.767 in Stud, CopperNon-stock product. Available to order - lead time may vary.
BrandPanduit
MFG #LCBX250-12-X
Werner Part #4004268
UPC074983126910
Non-stock product. Available to order - lead time may vary.
BrandPanduit
MFG #LCBX250-12-X
Werner Part #4004268
UPC074983126910
Product Description
Panduit Pan-Lug Compression Lug, 1-Hole, Series: LCBX, Flexible Copper Conductor, 250 kcmil, 262.6 kcmil Conductor, Die Code: P62, 35 kV, 42.767 in Stud, Straight Tongue, 1.28 in W x 0.17 in THK Tongue, 3.89 in Overall Length, Long/Standard Barrel, 0.7 in ID x 0.88 in OD x 2.24 in L Barrel, Specifications: 2.31 in L Wire Strip, Tin Plated Finish, 90 deg C, 23-1/8 in Mounting Hole, Copper, Yellow
Attributes
Documents
Applications
Features
Specifications
Attributes
Barrel Size0.7 in ID x 0.88 in OD x 2.24 in L
Barrel TypeLong/Standard
ColorYellow
Conductor size250 kcmil, 262.6 kcmil
Conductor TypeFlexible Copper
Country of OriginMX
Die CodeP62
ManufacturerPanduit
MaterialCopper
Mounting Hole Type23-1/8 in
Overall Length3.89 in
Package Height3.35 IN
Package Length5.85 in
Package Volume110481 cu-in
Package Weight2.75 lb
Package Width3.4 in
SeriesLCBX
Stud Size42.767 in
Temperature Rating90 deg C
Tongue Size1.28 in W x 0.17 in THK
Tongue TypeStraight
Type1-Hole
Type / Style1-Hole
Voltage Rating35 kV
Documents
Applications
For use with flexible and extra flexible stranded copper conductors
Features
- Long barrel maximizes number of crimps and provides premium wire pull-out strength and electrical performance
- Can be used with code conductor and flex conductor class G, H, I, K, M and diesel locomotive
- Generously beveled wire entry prevents bent back strands when inserting conductor into barrel
- Color-coded barrels marked with Panduit and specified competitor die index numbers for proper crimp die selection
- Inspection window to visually assure full conductor insertion
- Tin-plated to inhibit corrosion
- Consult cable manufacturer for voltage stress relief instructions with applications greater than 2000 V
- Can be used with code conductor and flex conductor class G, H, I, K, m and diesel locomotive
- Long barrel maximizes the number of crimps and provides premium wire pullout strength and electrical performance
- Generously beveled wire entry prevents bent back strands when inserting conductor into barrel
- Color coded barrels marked with Panduit and specified competitor die index numbers for proper crimp die selection
- Inspection window to visually assure full conductor insertion
- Tin plated to inhibit corrosion
Specifications
2.31 in L Wire Strip, Tin Plated Finish
