Panduit LCB500-12-6
Panduit Pan-Lug LCB500-12-6 1-Hole Compression Lug, 500 kcmil Stranded Copper Conductor, Die Code: P87, 42.767 in Stud, Copper
Panduit LCB500-12-6
Panduit Pan-Lug LCB500-12-6 1-Hole Compression Lug, 500 kcmil Stranded Copper Conductor, Die Code: P87, 42.767 in Stud, CopperNon-stock product. Available to order - lead time may vary.
BrandPanduit
MFG #LCB500-12-6
Werner Part #1081845
UPC074983901647
Non-stock product. Available to order - lead time may vary.
BrandPanduit
MFG #LCB500-12-6
Werner Part #1081845
UPC074983901647
Product Description
Panduit Pan-Lug Compression Lug, 1-Hole, Series: LCB, Stranded Copper Conductor, 500 kcmil Conductor, Die Code: P87, 35 kV, 42.767 in Stud, Straight Tongue, 1.54 in W x 0.22 in THK Tongue, 4.53 in Overall Length, Long Barrel, 0.84 in ID x 1.06 in OD x 2.5 in L Barrel, Specifications: 2-9/16 in L Wire Strip, Tin Plated Finish, 90 deg C, 2.56 in Mounting Hole, Copper, Brown
Attributes
Documents
Applications
Features
Specifications
Attributes
Barrel Size0.84 in ID x 1.06 in OD x 2.5 in L
Barrel TypeLong
ColorBrown
Conductor size500 kcmil
Conductor TypeStranded Copper
Country of OriginMX
Die CodeP87
ManufacturerPanduit
MaterialCopper
Mounting Hole Type2.56 in
Overall Length4.53 in
SeriesLCB
Stud Size42.767 in
Temperature Rating90 deg C
Tongue Size1.54 in W x 0.22 in THK
Tongue TypeStraight
Type1-Hole
Type / Style1-Hole
Voltage Rating35 kV
Documents
Applications
For use with stranded copper conductors
Features
- Long barrel maximizes number of crimps and provides premium wire pull-out strength and electrical performance
- Color-coded barrels marked with Panduit and specified competitor die index numbers for proper crimp die selection
- Enclosed barrel prevents corrosive material from entering barrel when used in harsh environments
- Tin-plated to inhibit corrosion
- Consult cable manufacturer for voltage stress relief instructions with applications greater than 2000 V
- High conductivity seamless copper tube
- Long barrel maximizes number of crimps and provides premium wire pull-out strength and electrical performance
- Color coded barrels marked with Panduit and specified competitor die index numbers for proper crimp die selection
- Enclosed barrel prevents corrosive material from entering barrel when used in harsh environments
- Tin plated to inhibit corrosion
- UL Listed and CSA Certified to 35 kV and temperature rated to 90 deg C when crimped with Panduit and specified competitor crimping tools and dies
- Without inspection window
Specifications
2-9/16 in L Wire Strip, Tin Plated Finish
