Panduit LCAX1/0-58-X
Panduit Pan-Lug LCAX1/0-58-X 1-Hole Compression Connector Lug, 1/0 AWG Flexible Copper Conductor, Die Code: P42, 42.952 in Stud, Tin Plated Copper
Panduit LCAX1/0-58-X
Panduit Pan-Lug LCAX1/0-58-X 1-Hole Compression Connector Lug, 1/0 AWG Flexible Copper Conductor, Die Code: P42, 42.952 in Stud, Tin Plated CopperNon-stock product. Available to order - lead time may vary.
BrandPanduit
MFG #LCAX1/0-58-X
Werner Part #3913770
UPC074983126583
Non-stock product. Available to order - lead time may vary.
BrandPanduit
MFG #LCAX1/0-58-X
Werner Part #3913770
UPC074983126583
Product Description
Panduit Pan-Lug Compression Connector Lug, 1-Hole, Series: LCAX, Flexible Copper Conductor, 1/0 AWG Conductor, Die Code: P42, 35 kV, 42.952 in Stud, Straight Tongue, 0.96 in W x 0.11 in THK Tongue, 2.38 in Overall Length, Standard Barrel, 0.45 in ID x 0.58 in OD x 0.72 in L Barrel, 3/4 in L Wire Strip, 90 deg C, 42.828 in Mounting Hole, Tin Plated Copper, Pink
Attributes
Documents
Features
Specifications
Attributes
Barrel Size0.45 in ID x 0.58 in OD x 0.72 in L
Barrel TypeStandard
ColorPink
Conductor size1/0 AWG
Conductor TypeFlexible Copper
Country of OriginMX
Die CodeP42
ManufacturerPanduit
MaterialTin Plated Copper
Mounting Hole Type42.828 in
Overall Length2.38 in
Package Height3.3 in
Package Length4.7 IN
Package Volume92565.5 cu-in
Package Weight0.75 lb
Package Width3.4 in
SeriesLCAX
Stud Size42.952 in
Temperature Rating90 deg C
Tongue Size0.96 in W x 0.11 in THK
Tongue TypeStraight
Type1-Hole
Type / Style1-Hole
Voltage Rating35 kV
Documents
Features
- Color-coded bands for proper die selection and crimp placement
- Inspection window to assure complete conductor insertion
- Tin plated to inhibit corrosion
- Generously beveled wire entry prevents bent back strands when inserting conductor into barrel
- Can be used with code conductor and flex conductor class G, H, I, K, M and diesel locomotive
- Consult cable manufacturer for voltage stress relief instructions with applications greater than 2000 V
- Can be used with code conductor and flex conductor class: G, H, I, K, M and diesel locomotive
- Generously beveled wire entry prevents bent back strands when inserting conductor into barrel
- Color coded barrels marked with Panduit and specified competitor die index numbers for proper crimp die selection
- Inspection window to visually assure full conductor insertion
- Tin plated to inhibit corrosion
- UL listed and CSA certified to 35 kV and temperature rated to 90 deg C when crimped with Panduit and specified competitor crimping tools and dies
Specifications
3/4 in L Wire Strip
