Panduit FSD78-12-D
Panduit Pan-Term FSD78-12-D Type FSD Single Insulated Wire Ferrule, 16 AWG Stranded Conductor, 0.73 in L, Copper, Black
Panduit FSD78-12-D
Panduit Pan-Term FSD78-12-D Type FSD Single Insulated Wire Ferrule, 16 AWG Stranded Conductor, 0.73 in L, Copper, BlackIn Stock: 5000more info
|
BrandPanduit
MFG #FSD78-12-D
Werner Part #1097605
UPC074983762576
In Stock: 5000more info
|
BrandPanduit
MFG #FSD78-12-D
Werner Part #1097605
UPC074983762576
Product Description
Panduit Pan-Term Wire Ferrule, Type FSD Single Insulated, Stranded Conductor, 16 AWG Conductor, 0.73 in Length, Seamless Barrel, 0.07 in ID x 0.47 in L Barrel, Specifications: 0.12 in Dia Maximum Wire Insulation, 5/8 in Mounting Hole, 5/8 in L Wire Strip, Polypropylene Insulation, 221 deg F, Copper, Tin Plated, Black
Attributes
Documents
Applications
Features
Specifications
Attributes
Barrel Size0.07 in ID x 0.47 in L
Barrel TypeSeamless
ColorBlack
Conductor size16 AWG
Conductor TypeStranded
Country of OriginDE
FinishTin Plated
ManufacturerPanduit
MaterialCopper
Package Height0.85 in
Package Length4.65 IN
Package Volume268739 cu-in
Package Weight0.2 lb
Package Width4.25 in
Temperature Rating221 deg F
TypeType FSD Single Insulated
Type / StyleType FSD DIN End Sleeve Single Insulated
Documents
Applications
Limited Space Panel Applications
Features
- Polypropylene insulation
- Continuously molded design provides consistent placement of ferrules in tool to ensure fast, reliable terminations
- Designed for use with the semi-automatic ferrule crimping tool CT-1000 for medium volume applications
- Designed with a seamless barrel to contain loose wire strands for superior terminations
- Eases insertion of wire into terminal block
- Meets DIN, UL and CSA standards for wire containment
Specifications
0.12 in Dia Maximum Wire Insulation, 5/8 in Mounting Hole, 5/8 in L Wire Strip, Polypropylene Insulation
