nVent HOFFMAN A84XM4024FTCG
nVent HOFFMAN A84XM4024FTCG A28M1 1-Door Heavy Duty Disconnect Enclosure With Panel, 84.12 in L x 40-1/4 in W x 24.12 in D, NEMA 12/IP55 NEMA Rating, Steel
nVent HOFFMAN A84XM4024FTCG
nVent HOFFMAN A84XM4024FTCG A28M1 1-Door Heavy Duty Disconnect Enclosure With Panel, 84.12 in L x 40-1/4 in W x 24.12 in D, NEMA 12/IP55 NEMA Rating, SteelNon-stock product. Available to order - lead time may vary.
Non-stock product. Available to order - lead time may vary.
Product Description
nVent HOFFMAN Disconnect Enclosure, 1-Door Heavy Duty, Series: A28M1, 84.12 in Length, 40-1/4 in Width, 24.12 in Depth, NEMA 12/IP55, Concealed Hinged Cover, 72 x 33-3/4 in Panel, Lock: 3-Point Latch/Padlock Handle, Freestanding Mount, Steel, Polyester Powder Painted, Gray
Attributes
Documents
Applications
Features
Included
Specifications
Attributes
ColorGray
Country of OriginMX
Cover TypeConcealed Hinged
FinishPolyester Powder Painted
ManufacturernVent
MaterialSteel
NEMA RatingNEMA 12/IP55
Panel Size72 x 33-3/4 in
SeriesA28M1
Type1-Door Heavy Duty
Documents
Applications
For simple, heavy duty and cost effective, this disconnect enclosure can be ordered with one to six doors to fit a range of applications
Features
- Seams continuously welded and ground smooth
- Body stiffeners in larger enclosures for extra rigidity
- Body flange trough excludes liquids and contaminants
- Heavy-duty lifting eyes anchor into reinforced top
- Removable centerposts permit easy panel installation
- Concealed, easy-to-remove hinges
- Heavy-duty 3-point latching mechanism operated by padlocking handle on all doors
- Panel supports
- Data pocket is high-impact thermoplastic
- Oil-resistant gasket
Included
Door Hardware
Specifications
- Seams continuously welded and ground smooth
- Body stiffeners in larger enclosures for extra rigidity
- Body flange trough excludes liquids and contaminants
- Heavy-duty lifting eyes anchor into reinforced top
- Removable centerposts permit easy panel installation
- Concealed, easy-to-remove hinges
- Heavy-duty 3-point latching mechanism operated by padlocking handle on all doors
- Panel supports
- Data pocket is high-impact thermoplastic
- Oil-resistant gasket
