Meltric 37-28043-4X
MELTRIC DECONTACTOR 37-28043-4X DS200 Switch Rated Male Inlet With Ground, 255/277/440/480 V AC, 200 A, 3 Poles, 4 Wires, Blue
Meltric 37-28043-4X
MELTRIC DECONTACTOR 37-28043-4X DS200 Switch Rated Male Inlet With Ground, 255/277/440/480 V AC, 200 A, 3 Poles, 4 Wires, BlueNon-stock product. Available to order - lead time may vary.
BrandMeltric
MFG #37-28043-4X
Werner Part #3834331
UPC784474646512
Non-stock product. Available to order - lead time may vary.
BrandMeltric
MFG #37-28043-4X
Werner Part #3834331
UPC784474646512
Product Description
MELTRIC DECONTACTOR Male Inlet, Switch Rated, Series: DS200, 255/277/440/480 V AC, 200 A, 60 Hz Frequency, 3 Pole, 4 Wires, NEMA 4X, IP54/IP55 Enclosure, -40 to 140 deg F, Screw Terminal, Metal, Blue, 5.59 in H x 5.75 in W x 4.69 in D Dimensions
Attributes
Documents
Applications
Features
Specifications
Attributes
ColorBlue
Country of OriginUS
Dimensions5.59 in H x 5.75 in W x 4.69 in D
Enclosure TypeIP54/IP55
Frequency Rating60 Hz
ManufacturerMeltric Corporation
MaterialMetal
NEMA RatingNEMA 4X
Number of Poles3
Number of Wires4
Package Type1/BX
SeriesDS200
Temperature Rating-40 to 140 deg F
Terminal TypeScrew
TypeSwitch Rated
Type / StyleSwitch Rated
Voltage Rating255/277/440/480 V AC
Applications
Heavy Industry and High Amperage Equipment Applications
Features
- Switch and hp rated (AC only)
- 65 to 100 kA short circuit rated
- Amperage rating up to 200 A
- Up to 4 auxiliary contacts
- Fiberglass reinforced thermoplastic polyester material offers great resistance to impact, corrosion and harsh environmental conditions
- Solid silver nickel contact surfaces provide superior conductivity, durability and corrosion resistance
Specifications
Standards/Approvals: ARRA Compliant|Buy American Act Compliant|RoHS Compliant|UL 2682/1682|CSA 182.1
