Littelfuse L60030C-1CDINR
Littelfuse POWR-GARD L60030C-1CDINR L600C Fuse Block, 600 V AC/DC, 30 A, Class: CC, 14 to 6 AWG Wire, 1 Poles
Littelfuse L60030C-1CDINR
Littelfuse POWR-GARD L60030C-1CDINR L600C Fuse Block, 600 V AC/DC, 30 A, Class: CC, 14 to 6 AWG Wire, 1 PolesNon-stock product. Available to order - lead time may vary.
BrandLittelfuse
MFG #L60030C-1CDINR
Werner Part #4206998
UPC079458161991
Non-stock product. Available to order - lead time may vary.
BrandLittelfuse
MFG #L60030C-1CDINR
Werner Part #4206998
UPC079458161991
Product Description
Littelfuse POWR-GARD Fuse Block, Series: L600C, 600 V AC/DC, 30 A, 1 Pole, Class: CC, Box Lug, 14 to 6 AWG Wire, DIN Rail Mount, 1-1/2 in Fuse Length, 13/32 in Fuse Dia, 125 deg C, For Use With: CCMR, KLDR and KLKR Series Fuse, Thermoplastic, 3.345 in L x 0.75 in W x 1.4 in H
Attributes
Documents
Features
Attributes
ClassCC
Connection TypeBox Lug
Country of OriginCN
Dimensions3.345 in L x 0.75 in W x 1.4 in H
Fuse Diameter13/32 in
Fuse Length1-1/2 in
ManufacturerLittelfuse
MaterialThermoplastic
Mounting TypeDIN Rail
Number of Poles1
Package TypeEACH
SeriesL600C
Size of Wire14 to 6 AWG
Suitable For Use WithCCMR, KLDR and KLKR Series Fuse
Temperature Rating125 deg C
Voltage Rating600 V AC/DC
Documents
Features
- 1200 VAC minimum dielectric strength
- Space saving design
- Universal mounting holes for easy replacement
- Indication offered on CD blocks
- Rejection feature that prevents the insertion of fuses with lower interrupting rating or voltage ratings
- Clip design reduces resistance and heat
- One hand release from DIN rail optional
- Covers available for all amperages to enhance safety
- Non-DIN rail fuse blocks have interlocking feature allowing ganging for any number of poles
- Copper box lug
- Zinc plated steel screw and captive pressure plate
- Tin plated copper alloy clip/terminals
- Lead (Pb) free
- 4 N-m torque rating
- Pressure plate with quick connect terminal
- Cu solid/stranded wire
- Spring-free mechanism allows for easy installation and removal
- Integral DIN rail mounting reduces assembly time
- Quick connect terminals accommodate side or top connection
