Leviton GFPL2-PLW
Leviton SmartlockPro Slim GFPL2-PLW Feed Through Self-Test Single Tamper Resistant GFCI Receptacle With LED Pilot Light, 125 V AC, 20 A, 2 Poles, 3 Wires, White
Leviton GFPL2-PLW
Leviton SmartlockPro Slim GFPL2-PLW Feed Through Self-Test Single Tamper Resistant GFCI Receptacle With LED Pilot Light, 125 V AC, 20 A, 2 Poles, 3 Wires, WhiteNon-stock product. Available to order - lead time may vary.
BrandLeviton
MFG #GFPL2-PLW
Werner Part #4200375
UPC078477723890
Non-stock product. Available to order - lead time may vary.
BrandLeviton
MFG #GFPL2-PLW
Werner Part #4200375
UPC078477723890
Product Description
Leviton SmartlockPro Slim GFCI Receptacle, Feed Through Self-Test Single Tamper Resistant, 125 V AC, 20 A, 1 hp, 2 Pole, 3 Wires, NEMA 5-20R Enclosure, -35 to 66 deg C, Polybutylene Terephthalate/Polycarbonate, White, 1.74 in W x 1.36 in D x 4.05 in H Dimensions
Attributes
Documents
Applications
Features
Specifications
Warranty
Attributes
ColorWhite
Country of OriginCN
Dimensions1.74 in W x 1.36 in D x 4.05 in H
Electrical Ratings125 VAC, 20 A, 1 hp
Enclosure TypeNEMA 5-20R
Frequency Rating60 Hz
GradeExtra Heavy-Duty Industrial Specification Grade
Horsepower1 hp
Lamp TypeLED
ManufacturerLeviton
MaterialPolybutylene Terephthalate/Polycarbonate
NEMA RatingWD-1 & WD-6
Number of Poles2
Number of Wires3
Package Height4.75 in
Package Length8.75 in
Package TypeEACH
Package Weight3.88 lbs
Package Width5 in
Temperature Rating-35 to 66 deg C
Terminal TypeBack/Side Wire
TypeFeed Through Self-Test Single Tamper Resistant
Type / StyleFeed Through Self-Test Single Tamper Resistant
Voltage Rating125 V AC
Documents
Applications
Industrial Applications
Features
- Patented bridge contact design provides individual sets of contacts for GFCI receptacle face and downstream receptacles, no power will be delivered to receptacle face if improperly wired (line load reversed)
- Improved immunity to high frequency noise reduces nuisance tripping
- Advanced electronics design provides superior resistance to electrical surges and over voltages
- Low profile design is easy to install in all electrical boxes
- Patented SmartlockPro protection prevents resetting when ground fault protection has been lost
- Ideal for equipment protection on dedicated branch circuits
- High visibility LED provides a visual indication of power status - ideal for applications where receptacles are not easily accessible
Specifications
Standards/Approvals: ARRA Compliant|Buy American Act Compliant|RoHS Compliant|UL Listed|CSA Certified|NOM-ANCE Certified
Warranty
2 Years Limited
