Leviton 8400-W
Leviton 8400-W Duplex Extra Heavy Duty Wide Body Straight Blade Receptacle, 250 V AC, 20 A, 2 Poles, 3 Wires, White
Leviton 8400-W
Leviton 8400-W Duplex Extra Heavy Duty Wide Body Straight Blade Receptacle, 250 V AC, 20 A, 2 Poles, 3 Wires, WhiteNon-stock product. Available to order - lead time may vary.
BrandLeviton
MFG #8400-W
Werner Part #3990289
UPC078477492574
Non-stock product. Available to order - lead time may vary.
BrandLeviton
MFG #8400-W
Werner Part #3990289
UPC078477492574
Product Description
Leviton Straight Blade Receptacle, Duplex Extra Heavy Duty Wide Body, 250 V AC, 20 A, 2 hp, 2 Pole, 3 Wires, NEMA 6-20R NEMA Rating, Commercial Grade, -40 to 60 deg C, Back/Side Wire Terminal, Thermoplastic, White, 46 in H x 1.53 in W x 1.11 in D Dimensions
Attributes
Documents
Warranty
Features
Specifications
Attributes
ColorWhite
Country of OriginMX
Dimensions46 in H x 1.53 in W x 1.11 in D
GradeCommercial
Horsepower2 hp
ManufacturerLeviton
MaterialThermoplastic
NEMA RatingNEMA 6-20R
Number of Poles2
Number of Wires3
Package Height7.75 in
Package Length12.25 in
Package TypeEACH
Package Weight12.44 lbs
Package Width8.75 in
Temperature Rating-40 to 60 deg C
Terminal TypeBack/Side Wire
TypeDuplex Extra Heavy Duty Wide Body
Type / StyleDuplex Extra Heavy Duty Wide Body
Voltage Rating250 V AC
Warranty
10 Years
Features
- Impact resistant thermoplastic nylon cover and body
- Four corner latches securely fasten face
- Extra heavy duty triple-wipe, brass T contacts for superior contact and conductivity
- High performance brass #10-32 terminal screws to reduce conductor oxidation
- Back and side wire ground termination brass strap version
- Back and side wiring options
- Break-OFF tabs allow easy 2-circuit conversion
- Apron barrier to prevent accidental contact between terminal screw heads and metal box
- Exclusive V-shaped, serrated back wiring clamps for superior contact and conductivity
- Power Indication provides permanent green dot lens with 100000 hr LED status indicator
Specifications
Standards/Approvals: ARRA Compliant|Buy American Act Compliant|RoHS Compliant|NEMA WD1/WD6|ANSI C73|NOM 057|CSA C22.2 No. 42 File No. 152105|UL Federal Specification W-C-596 File No. E13399|UL 498HG File No. E13399|UL94 V-2 Flammability Rating
