Cutler-Hammer Series XTRM10A22A
EATON XTRM10A22A Miniature Control Relay, 10 A, 2NO-2NC 2 Form C Contact, 110/120 VAC V Coil
Cutler-Hammer Series XTRM10A22A
EATON XTRM10A22A Miniature Control Relay, 10 A, 2NO-2NC 2 Form C Contact, 110/120 VAC V CoilNon-stock product. Available to order - lead time may vary.
BrandCutler-Hammer Series
MFG #XTRM10A22A
Werner Part #3962915
Non-stock product. Available to order - lead time may vary.
BrandCutler-Hammer Series
MFG #XTRM10A22A
Werner Part #3962915
Product Description
EATON Miniature Control Relay, Series: XT Series, 10 A, 50/60 Hz Frequency, 110/120 VAC Coil, 2NO-2NC 2 Form C Contact Form, 6 A at 220/240 V AC, 4 A at 380/400/415 V AC Contact, Screw Terminal, IP20 Enclosure, -13 to 122 deg F, 2-1/2 x 2 x 2-/2 in Dimensions
Attributes
Documents
Applications
Features
Attributes
Coil Voltage110/120 V AC
Contact Form2NO-2NC 2 Form C
Contact Rating6 A at 220/240 V AC, 4 A at 380/400/415 V AC
Country of OriginDE
Dimensions2-1/2 x 2 x 2-/2 in
Enclosure TypeIP20
Frequency Rating50/60 Hz
ManufacturerEaton
SeriesXT Series
Temperature Rating-13 to 122 deg F
Terminal TypeScrew
Type / StyleSKU
Applications
Commercial, Institutional Buildings and Structures
Features
- On delay and multi-function timers
- The XTRE control relays have positively driven contacts between the relay and the auxiliary contact modules as well as within the auxiliary contact modules
