Cutler-Hammer Series XTPB6P3BC1
EATON XTPB6P3BC1 B Frame Motor Protector, ON/OFF Action, 2 Poles, IP20 Enclosure
Cutler-Hammer Series XTPB6P3BC1
EATON XTPB6P3BC1 B Frame Motor Protector, ON/OFF Action, 2 Poles, IP20 EnclosureInventory Not Available
Inventory Not Available
Product Description
EATON Motor Protector, B Frame, Series: XT Series, 690 V AC, 6.3 A, 40 to 60 Hz Frequency, 4 kW Wattage, 2 Pole, Setting: 3 A, Manual Reset, 3 ph, Screw Connection, ON/OFF Action, Bi-Metal Overload Relay, 4 to 6.3 A Full Load, Pushbutton Control, IP20 Enclosure, -25 to 55 deg C Operating, 1.77 in W x 3.35 in D x 3.66 in H Dimensions
Attributes
Documents
Applications
Warranty
Features
Attributes
ActionON/OFF
Connection TypeScrew
Country of OriginDE
Dimensions1.77 in W x 3.35 in D x 3.66 in H
Enclosure TypeIP20
Frequency Rating40 to 60 Hz
Full Load Current4 to 6.3 A
ManufacturerEaton
Number of Poles2
Operating Temperature-25 to 55 deg C
Phase3
SeriesXT Series
Type / StyleB Frame
Wattage4 kW
Documents
Applications
Commercial, Institutional Buildings, Structures - Safety and Security Systems
Warranty
1 year
Features
- 4:1 maximum to minimum over current dial setting range
- Selectable trip class (5, 10, 15, 20)
- Interchangeable trip units
- Three base units (12, 32 and 65 A)
- Common accessories with the XTPR
