Cutler-Hammer Series XTCE250L22A
EATON XTCE250L22A Full Voltage Non-Reversing IEC Contactor, 110 to 250 V DC V Coil, 250 A, 2NO-2NC Contact, 3 Poles
Cutler-Hammer Series XTCE250L22A
EATON XTCE250L22A Full Voltage Non-Reversing IEC Contactor, 110 to 250 V DC V Coil, 250 A, 2NO-2NC Contact, 3 PolesNon-stock product. Available to order - lead time may vary.
BrandCutler-Hammer Series
MFG #XTCE250L22A
Werner Part #3945659
Non-stock product. Available to order - lead time may vary.
BrandCutler-Hammer Series
MFG #XTCE250L22A
Werner Part #3945659
Product Description
EATON IEC Contactor, Full Voltage Non-Reversing, Series: XT Series, 110 to 250 V DC Coil, 250 A Maximum Load Current, 75 hp at 200 VAC 3 ph, 100 hp at 230 VAC 3 ph, 200 hp at 460 VAC 3 ph, 250 hp at 575 VAC 3 ph Coil, 3 Pole, 40/60 Hz Frequency, 2NO-2NC Contact Configuration, 4 Auxiliary Contacts, 140 mm Size, Screw Terminal, IP20 Enclosure, -13 to 122 deg F Operating, DIN Rail/Panel Mounting, 8.189 x 5.5118 x 7.0866 in Dimensions
Attributes
Documents
Applications
Warranty
Features
Attributes
Coil Power Rating75 hp at 200 VAC 3 ph, 100 hp at 230 VAC 3 ph, 200 hp at 460 VAC 3 ph, 250 hp at 575 VAC 3 ph
Coil Voltage110 to 250 V DC
Contact Configuration2NO-2NC
Country of OriginRO
Dimensions8.189 x 5.5118 x 7.0866 in
Enclosure TypeIP20
Frequency Rating40/60 Hz
Full Load CurrentMax: 250 A
ManufacturerEaton
Maximum Load Current250 A
Mounting TypeDIN Rail/Panel
Number of Auxiliary Contacts4
Number of Poles3
Operating Temperature-13 to 122 deg F
SeriesXT Series
Size140 mm
Terminal TypeScrew
Type / StyleL-Frame Full Voltage Non-Reversing
Documents
Applications
Electrical Assemblies, Panels and EOEMs and Other Applications
Warranty
1 year
Features
- Electronic coil controller allows contactors to reduce power consumption and generate less heat, resulting in lower cooling requirements, the ability to mount more contactors/starters per cabinet and an extended life on pilot devices that carry control signals
- AC and DC devices with the same dimensions achieved with an electronically controlled coil system allow for space savings and reduced engineering design time
- Integrated suppressors in DC controlled contactors offers reductions in total logistics and inventory costs by limiting the number of products ordered and stocked
- Wiring is not required, therefore increasing installation and maintenance efficiency
- Expanded range of DC coil control voltages, allows reliable operation through fluctuations in control voltages
- Twin terminals with separate sockets in contactors up to 400 A offer installation and application flexibility when using different size wires
- The improved integrity of the connections reduces cabling faults
- 75 hp at 220/230 VAC, 132 hp at 380/400 VAC, 240 hp at 415 VAC, 108 hp at 660/690 VAC coil power rating
