Cutler-Hammer Series NGS312033E
EATON NGS312033E Type NGS Molded Case Circuit Breaker, 480 V AC, 1200 A, 50/85 kA Interrupt, 3 Poles, Electronic Trip
Cutler-Hammer Series NGS312033E
EATON NGS312033E Type NGS Molded Case Circuit Breaker, 480 V AC, 1200 A, 50/85 kA Interrupt, 3 Poles, Electronic TripNon-stock product. Available to order - lead time may vary.
Non-stock product. Available to order - lead time may vary.
Product Description
EATON Molded Case Circuit Breaker, Type NGS, Series: G Series, 480 V AC, 1200 A, 50/60 Hz Frequency, 50/85 kA Interrupt, NG Frame, Electronic Trip, 3 Pole, Imperial Line/Load Connection, 40 deg C, 6 x 9 x 9 in Dimensions
Attributes
Documents
Applications
Included
Warranty
Features
Attributes
Connection TypeImperial Line/Load
Country of OriginUS
Dimensions6 x 9 x 9 in
Enclosure TypeNEMA 3R
FrameNG
Frequency Rating50/60 Hz
Interrupt Rating50/85 kA
ManufacturerEaton
Mounting TypeSurface
Number of Poles3
Package TypeEACH
Phase3
SeriesG Series
Temperature Rating40 deg C
Terminal Type3/8 in Stud/Single Mechanical
Trip TypeElectronic
TypeType NGS
Type / StyleType NGS
Voltage480 VAC
Documents
Applications
For use with all model A or T type Visi-Flex disconnect switchesand electrical assemblies, panels and EOEMs applications
Included
Frame, Trip Unit, Mounting Hardware and Standard Terminals
Warranty
1 year
Features
- Compact design frees up panel space
- Common field-fit internal accessories make installation and custom configuration easy
- Advanced trip unit functionality offers a wide range of adjustment for maximum flexibility
- Patented contact design features high speed "blow-open" action, resulting in superior performance
- Suitable for reverse feed applications
- 80% rated
- Imperial tapped line and load terminal
- 85 kA at 240 VAC, 50 kA at 480 VAC interrupt rating
