Cutler-Hammer Series LGH3350FAG
EATON LGH3350FAG Type LGH Molded Case Circuit Breaker, 600 V AC, 350 A, 35 kA Interrupt, 3 Poles, Thermal Magnetic Trip
Cutler-Hammer Series LGH3350FAG
EATON LGH3350FAG Type LGH Molded Case Circuit Breaker, 600 V AC, 350 A, 35 kA Interrupt, 3 Poles, Thermal Magnetic TripNon-stock product. Available to order - lead time may vary.
BrandCutler-Hammer Series
MFG #LGH3350FAG
Werner Part #3951763
UPC782116142750
Non-stock product. Available to order - lead time may vary.
BrandCutler-Hammer Series
MFG #LGH3350FAG
Werner Part #3951763
UPC782116142750
Product Description
EATON Molded Case Circuit Breaker, Type LGH, Series: G Series, 600 V AC, 350 A, 50/60 Hz, 35 kA Interrupt, LG Frame, Thermal Magnetic Trip, 3 Pole, Line/Load, 40 deg C, 4.09 x 5.48 x 5.48 in
Attributes
Documents
Applications
Included
Features
Attributes
Connection TypeLine/Load
Country of OriginDO
Dimensions4.09 x 5.48 x 5.48 in
Enclosure TypeNEMA 3R
FrameLG
Frequency Rating50/60 Hz
Horsepower60 hp
Insulation TypeNon-Insulated
Interrupt Rating35 kA
ManufacturerEaton
MaterialSteel
Mounting TypeSurface
Number of Poles3
Number of Wires3
Package TypeEACH
Phase3
SeriesG Series
Short Circuit Current Rating200 kA
Temperature Rating40 deg C
Terminal TypeLug
Trip TypeThermal Magnetic
TypeType LGH
Type / StyleType LGH
Voltage600 VAC
Documents
Applications
For use with pipe hangers, electrical assemblies, panels and OEMs
Included
Frame, Trip Unit, Mounting Hardware and Standard Terminals
Features
- Compact design frees up panel space
- Common field-fit internal accessories make installation and custom configuration easy
- Advanced trip unit functionality offers a wide range of adjustment for maximum flexibility
- Patented contact design features high speed "blow-open" action, resulting in superior performance
- Metric mounting hardware
- 100 kA at 240 VAC, 65 kA at 480 VAC, 35 kA at 600 VAC interrupt rating
