Cutler-Hammer Series JGH3125FAG
EATON JGH3125FAG Type JGH Molded Case Circuit Breaker, 600 V AC, 125 A, 25/65/100 kA Interrupt, 3 Poles, Thermal Magnetic Trip
Cutler-Hammer Series JGH3125FAG
EATON JGH3125FAG Type JGH Molded Case Circuit Breaker, 600 V AC, 125 A, 25/65/100 kA Interrupt, 3 Poles, Thermal Magnetic TripNon-stock product. Available to order - lead time may vary.
BrandCutler-Hammer Series
MFG #JGH3125FAG
Werner Part #3952305
UPC782113963419
Non-stock product. Available to order - lead time may vary.
BrandCutler-Hammer Series
MFG #JGH3125FAG
Werner Part #3952305
UPC782113963419
Product Description
EATON Molded Case Circuit Breaker, Type JGH, Series: G Series, 600 V AC, 125 A, 50/60 Hz Frequency, 25/65/100 kA Interrupt, JG Frame, Thermal Magnetic Trip, 625 to 1250 A Trip, 3 Pole, Line/Load Standard Connection, 40 deg C, 3.57 x 4.13 x 4.13 in Dimensions
Attributes
Documents
Applications
Included
Warranty
Features
Attributes
ColorBlack
Connection TypeLine/Load Standard
Country of OriginDO
Dimensions3.57 x 4.13 x 4.13 in
FinishTin Plated
FrameJG
Frequency Rating50/60 Hz
Interrupt Rating25/65/100 kA
ManufacturerEaton
MaterialAluminum/Thermoplastic
Number of Poles3
Package TypeEACH
Primary Connection/Pole1
Secondary Connection/Pole(1) 3/8-16 x 1 in Stud
SeriesG Series
Short Circuit Current Rating10 kA
Size of Wire6 AWG to 500 kcmil Cu/Al Line
Temperature Rating40 deg C
Trip Range625 to 1250 A
Trip TypeThermal Magnetic
TypeType JGH
Type / StyleType JGH
Voltage600 VAC
Documents
Applications
Indicating Light Applications
Included
Metric Mounting Hardware
Warranty
1 year
Features
- 100 kA at 240 VAC, 65 kA at 480 VAC, 25 kA at 600 VAC interrupt rating
