Cutler-Hammer Series JGC3225FAG
EATON JGC3225FAG Molded Case Circuit Breaker, 600 V AC, 225 A, 35 kA Interrupt, 3 Poles, Thermal Magnetic Trip
Cutler-Hammer Series JGC3225FAG
EATON JGC3225FAG Molded Case Circuit Breaker, 600 V AC, 225 A, 35 kA Interrupt, 3 Poles, Thermal Magnetic TripNon-stock product. Available to order - lead time may vary.
Non-stock product. Available to order - lead time may vary.
Product Description
EATON Molded Case Circuit Breaker, Series: G Series, 600 V AC, 225 A, 50/60 Hz, 35 kA Interrupt, JG Frame, Thermal Magnetic Trip, 1125 to 2250 A Trip, 3 Pole, 3 ph, Toggle Handle Actuator, Standard Line/Load, -20 to 70 deg C, 3.57 x 4.13 x 4.13 in, Glass Polyester
Attributes
Documents
Applications
Included
Warranty
Features
Attributes
Actuator TypeToggle Handle
Connection TypeStandard Line/Load
Country of OriginDO
Dimensions3.57 x 4.13 x 4.13 in
FrameJG
Frequency Rating50/60 Hz
Interrupt Rating35 kA
ManufacturerEaton
MaterialGlass Polyester
Number of Poles3
Package TypeEACH
Phase3
SeriesG Series
Suitable For Use WithStandard Class J Fused Rotary Disconnect Switch
Temperature Rating-20 to 70 deg C
Trip Range1125 to 2250 A
Trip TypeThermal Magnetic
Type / StyleComplete breaker
Voltage600 VAC
Documents
Applications
Electrical Assemblies, Panels and OEMs Applications
Included
Metric Mounting Hardware
Warranty
1 year
Features
- Compact design frees up panel space
- Common field-fit internal accessories make installation and custom configuration easy
- Advanced trip unit functionality offers a wide range of adjustment for maximum flexibility
- Patented contact design features high speed "blow-open" action, resulting in superior performance
- Mounting hardware and lugs are included for convenience, eliminating the need for separate parts orders
- Circuit breakers significantly outperform the calculations listed in the institute of electrical and electronic engineers (IEEE) standard 1584, guide for performing arc flash hazard calculations
- Meets the requirements of UL, CSA, IEC, CCC and CE, providing a truly global design and worldwide acceptance
- 200 kA at 240 VAC, 100 kA at 415/480 VAC, 35 kA at 600 VAC interrupt rating
