Cutler-Hammer Series FAZ-D6/3-NA
EATON FAZ-D6/3-NA Current Limiting Miniature Circuit Breaker, 277/480 V AC, 6 A, 10 to 14 kA Interrupt, 3 Poles, Thermal Magnetic Trip
Cutler-Hammer Series FAZ-D6/3-NA
EATON FAZ-D6/3-NA Current Limiting Miniature Circuit Breaker, 277/480 V AC, 6 A, 10 to 14 kA Interrupt, 3 Poles, Thermal Magnetic TripNon-stock product. Available to order - lead time may vary.
Non-stock product. Available to order - lead time may vary.
Product Description
EATON Miniature Circuit Breaker, Current Limiting, Series: FAZ-NA, 277/480 V AC, 6 A, 50/60 Hz Frequency, 10 to 14 kA Interrupt, Thermal Magnetic Trip, 10 to 20X Trip, 3 Pole, Toggle Actuator, Screw/Standard Terminal Connection, 18 to 6 AWG, 18 to 10 AWG Wire, DIN Rail Mounting, 40 deg C, 2.97 in W x 2.09 in D x 4.13 in H Dimensions
Attributes
Documents
Applications
Features
Specifications
Attributes
Connection TypeScrew/Standard Terminal
Country of OriginES
Dimensions2.97 in W x 2.09 in D x 4.13 in H
Frequency Rating50/60 Hz
Interrupt Rating10 to 14 kA
ManufacturerEaton
MaterialAluminum/Copper
Number of Poles3
Package TypeEACH
SeriesFAZ-NA
Size of Wire18 to 6 AWG
Suitable For Use WithFusible Disconnect Safety Switch
Temperature Rating40 deg C
Trip Range10 to 20X
Trip TypeThermal Magnetic
TypeCurrent Limiting
Voltage277/480 VAC
Documents
Applications
Branch Circuit Device, Circuit Protection, Convenience Receptacle Circuits, Motor Control Circuits, HACR Internal/External Equipment, PLC I/O Points, Computers, Power Supplies, Control Instrumentation, Relays, UPS, Power Conditioners, Conventional Energy, Renewable Energy and Alternative Energy Generation, Datacenters, IT Space - CI, Hyper Converged, Marine Vessels and Equipment and Industrial Applications
Features
- Current limiting design provides fast short-circuit interruption that reduces the let-through energy, which can damage the circuit
- Suitable for branch circuit device protection
- Thermal magnetic over current protection
- Three levels of short circuit protection, categorized by B, C and D curves
- Trip-free design breaker can not be defeated by holding the handle in the On position
- Captive screws cannot be lost
- Field installable shunt trip and auxiliary switch subsequent mounting
- Contact position indicator (red/green)
- Possibility for sealing the toggle in "On/Off" position
Specifications
600 VAC, 60 A
